GE UR series

B-36 L60 Line Phase Comparison System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
7266 Phase Directional Overcurrent 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
7267 Phase Directional Overcurrent 1 Events 0 to 1 --- 1 F102 0 (Disabled)
7268 Reserved (8 items) 0 to 1 --- 1 F001 0
7270 ...Repeated for Phase Directional Overcurrent 2
Neutral Directional Overcurrent (Read/Write Grouped Setting) (2 modules)
7280 Neutral Directional Overcurrent 1 Function 0 to 1 --- 1 F102 0 (Disabled)
7281 Neutral Directional Overcurrent 1 Source 0 to 5 --- 1 F167 0 (SRC 1)
7282 Neutral Directional Overcurrent 1 Polarizing 0 to 2 --- 1 F230 0 (Voltage)
7283 Neutral Directional Overcurrent 1 Forward ECA -90 to 90 ° Lag 1 F002 75
7284 Neutral Directional Overcurrent 1 Forward Limit Angle 40 to 90 degrees 1 F001 90
7285 Neutral Directional Overcurrent 1 Forward Pickup 0.002 to 30 pu 0.001 F001 50
7286 Neutral Directional Overcurrent 1 Reverse Limit Angle 40 to 90 degrees 1 F001 90
7287 Neutral Directional Overcurrent 1 Reverse Pickup 0.002 to 30 pu 0.001 F001 50
7288 Neutral Directional Overcurrent 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
7289 Neutral Directional Overcurrent 1 Block 0 to 65535 --- 1 F300 0
728A Neutral Directional Overcurrent 1 Events 0 to 1 --- 1 F102 0 (Disabled)
728B Neutral Directional Overcurrent 1 Polarizing Voltage 0 to 1 --- 1 F231 0 (Calculated V0)
728C Neutral Directional Overcurrent 1 Op Current 0 to 1 --- 1 F196 0 (Calculated 3I0)
728D Neutral Directional Overcurrent 1 Offset 0 to 250 ohms 0.01 F001 0
728E Neutral Directional Overcurrent 1 Pos Seq Restraint 0 to 0.5 --- 0.001 F001 63
728F Reserved 0 to 1 --- 1 F001 0
7290 ...Repeated for Neutral Directional Overcurrent 2
Negative-sequence directional overcurrent (read/write grouped settings) (2 modules)
72A0 Negative Sequence Directional Overcurrent 1 Function 0 to 1 --- 1 F102 0 (Disabled)
72A1 Negative Sequence Directional Overcurrent 1 Source 0 to 5 --- 1 F167 0 (SRC 1)
72A2 Negative Sequence Directional Overcurrent 1 Type 0 to 1 --- 1 F179 0 (Neg Sequence)
72A3 Neg Sequence Directional Overcurrent 1 Forward ECA 0 to 90 ° Lag 1 F002 75
72A4 Neg Seq Directional Overcurrent 1 Forward Limit Angle 40 to 90 degrees 1 F001 90
72A5 Neg Sequence Directional Overcurrent 1 Forward Pickup 0.015 to 30 pu 0.05 F001 5
72A6 Neg Seq Directional Overcurrent 1 Reverse Limit Angle 40 to 90 degrees 1 F001 90
72A7 Neg Sequence Directional Overcurrent 1 Reverse Pickup 0.015 to 30 pu 0.05 F001 5
72A8 Negative Sequence Directional Overcurrent 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
72A9 Negative Sequence Directional Overcurrent 1 Block 0 to 65535 --- 1 F300 0
72AA Negative Sequence Directional Overcurrent 1 Events 0 to 1 --- 1 F102 0 (Disabled)
72AB Negative Sequence Directional Overcurrent 1 Offset 0 to 250 ohms 0.01 F001 0
72AC Neg Seq Directional Overcurrent 1 Pos Seq Restraint 0 to 0.5 --- 0.001 F001 63
72AD Reserved (3 items) 0 to 1 --- 1 F001 0
72B0 ...Repeated for Neg Seq Directional Overcurrent 2
Breaker Arcing Current Settings (Read/Write Setting)
72C0 Breaker 1 Arcing Current Function 0 to 1 --- 1 F102 0 (Disabled)
72C1 Breaker 1 Arcing Current Source 0 to 5 --- 1 F167 0 (SRC 1)
72C2 Breaker 1 Arcing Current Initiate A 0 to 65535 --- 1 F300 0
72C3 Breaker 1 Arcing Current Initiate B 0 to 65535 --- 1 F300 0
72C4 Breaker 1 Arcing Current Initiate C 0 to 65535 --- 1 F300 0
72C5 Breaker 1 Arcing Current Delay 0 to 65.535 s 0.001 F001 0
72C6 Breaker 1 Arcing Current Limit 0 to 50000 kA
2
-cyc 1 F001 1000
72C7 Breaker 1 Arcing Current Block 0 to 65535 --- 1 F300 0
72C8 Breaker 1 Arcing Current Target 0 to 2 --- 1 F109 0 (Self-reset)
72C9 Breaker 1 Arcing Current Events 0 to 1 --- 1 F102 0 (Disabled)
72CA ...Repeated for Breaker 2 Arcing Current
dcmA Inputs (Read/Write Setting) (24 modules)
7300 dcmA Inputs 1 Function 0 to 1 --- 1 F102 0 (Disabled)
7301 dcmA Inputs 1 ID --- --- --- F205 “DCMA I 1"
7307 Reserved 1 (4 items) 0 to 65535 --- 1 F001 0
Table B–9: MODBUS MEMORY MAP (Sheet 28 of 55)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
