75FD ...Repeated for disconnect switch 10
7612 ...Repeated for disconnect switch 11
7627 ...Repeated for disconnect switch 12
763C ...Repeated for disconnect switch 13
7651 ...Repeated for disconnect switch 14
7666 ...Repeated for disconnect switch 15
767B ...Repeated for disconnect switch 16
User Programmable Pushbuttons (Read/Write Setting) (16 modules)
7B60 User Programmable Pushbutton 1 Function 0 to 2 --- 1 F109 2 (Disabled)
7B61 User Programmable Pushbutton 1 Top Line --- --- --- F202 (none)
7B6B User Programmable Pushbutton 1 On Text --- --- --- F202 (none)
7B75 User Programmable Pushbutton 1 Off Text --- --- --- F202 (none)
7B7F User Programmable Pushbutton 1 Drop-Out Time 0 to 60 s 0.05 F001 0
7B80 User Programmable Pushbutton 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
7B81 User Programmable Pushbutton 1 Events 0 to 1 --- 1 F102 0 (Disabled)
7B82 User Programmable Pushbutton 1 LED Operand 0 to 65535 --- 1 F300 0
7B83 User Programmable Pushbutton 1 Autoreset Delay 0 to 600 s 0.05 F001 0
7B84 User Programmable Pushbutton 1 Autoreset Function 0 to 1 --- 1 F102 0 (Disabled)
7B85 User Programmable Pushbutton 1 Local Lock 0 to 65535 --- 1 F300 0
7B86 User Programmable Pushbutton 1 Message Priority 0 to 2 --- 1 F220 0 (Disabled)
7B87 User Programmable Pushbutton 1 Remote Lock 0 to 65535 --- 1 F300 0
7B88 User Programmable Pushbutton 1 Reset 0 to 65535 --- 1 F300 0
7B89 User Programmable Pushbutton 1 Set 0 to 65535 --- 1 F300 0
7B8A User Programmable Pushbutton 1 Hold 0 to 10 s 0.1 F001 1
7B8B ...Repeated for User Programmable Pushbutton 2
7BB6 ...Repeated for User Programmable Pushbutton 3
7BE1 ...Repeated for User Programmable Pushbutton 4
7C0C ...Repeated for User Programmable Pushbutton 5
7C37 ...Repeated for User Programmable Pushbutton 6
7C62 ...Repeated for User Programmable Pushbutton 7
7C8D ...Repeated for User Programmable Pushbutton 8
7CB8 ...Repeated for User Programmable Pushbutton 9
7CE3 ...Repeated for User Programmable Pushbutton 10
7D0E ...Repeated for User Programmable Pushbutton 11
7D39 ...Repeated for User Programmable Pushbutton 12
7D64 ...Repeated for User Programmable Pushbutton 13
7D8F ...Repeated for User Programmable Pushbutton 14
7DBA ...Repeated for User Programmable Pushbutton 15
7DE5 ...Repeated for User Programmable Pushbutton 16
Neutral Overvoltage (Read/Write Grouped Setting) (3 modules)
7F00 Neutral Overvoltage 1 Function 0 to 1 --- 1 F102 0 (Disabled)
7F01 Neutral Overvoltage 1 Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
7F02 Neutral Overvoltage 1 Pickup 0 to 3.00 pu 0.001 F001 300
7F03 Neutral Overvoltage 1 Pickup Delay 0 to 600 s 0.01 F001 100
7F04 Neutral Overvoltage 1 Reset Delay 0 to 600 s 0.01 F001 100
7F05 Neutral Overvoltage 1 Block 0 to 65535 --- 1 F300 0
7F06 Neutral Overvoltage 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
7F07 Neutral Overvoltage 1 Events 0 to 1 --- 1 F102 0 (Disabled)
7F08 Neutral Overvoltage 1 Curves 0 to 3 --- 1 F116 0 (Definite Time)
7F09 Reserved (8 items) 0 to 65535 --- 1 F001 0
7F10 ...Repeated for Neutral Overvoltage 2
7F20 ...Repeated for Neutral Overvoltage 3
Auxiliary Overvoltage (Read/Write Grouped Setting) (3 modules)
7F30 Auxiliary Overvoltage 1 Function 0 to 1 --- 1 F102 0 (Disabled)
Table B–9: MODBUS MEMORY MAP (Sheet 30 of 55)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
