GE UR series

GE Multilin L60 Line Phase Comparison System B-39
APPENDIX B B.4 MEMORY MAPPING
B
7F31 Auxiliary Overvoltage 1 Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
7F32 Auxiliary Overvoltage 1 Pickup 0 to 3 pu 0.001 F001 300
7F33 Auxiliary Overvoltage 1 Pickup Delay 0 to 600 s 0.01 F001 100
7F34 Auxiliary Overvoltage 1 Reset Delay 0 to 600 s 0.01 F001 100
7F35 Auxiliary Overvoltage 1 Block 0 to 65535 --- 1 F300 0
7F36 Auxiliary Overvoltage 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
7F37 Auxiliary Overvoltage 1 Events 0 to 1 --- 1 F102 0 (Disabled)
7F38 Reserved (8 items) 0 to 65535 --- 1 F001 0
7F40 ...Repeated for Auxiliary Overvoltage 2
7F50 ...Repeated for Auxiliary Overvoltage 3
Auxiliary Undervoltage (Read/Write Grouped Setting) (3 modules)
7F60 Auxiliary Undervoltage 1 Function 0 to 1 --- 1 F102 0 (Disabled)
7F61 Auxiliary Undervoltage 1 Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
7F62 Auxiliary Undervoltage 1 Pickup 0 to 3 pu 0.001 F001 700
7F63 Auxiliary Undervoltage 1 Delay 0 to 600 s 0.01 F001 100
7F64 Auxiliary Undervoltage 1 Curve 0 to 1 --- 1 F111 0 (Definite Time)
7F65 Auxiliary Undervoltage 1 Minimum Voltage 0 to 3 pu 0.001 F001 100
7F66 Auxiliary Undervoltage 1 Block 0 to 65535 --- 1 F300 0
7F67 Auxiliary Undervoltage 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
7F68 Auxiliary Undervoltage 1 Events 0 to 1 --- 1 F102 0 (Disabled)
7F69 Reserved (7 items) 0 to 65535 --- 1 F001 0
7F70 ...Repeated for Auxiliary Undervoltage 2
7F80 ...Repeated for Auxiliary Undervoltage 3
Frequency (Read Only)
8000 Tracking Frequency --- Hz --- F001 0
Breaker Failure (Read/Write Grouped Setting) (2 modules)
8600 Breaker Failure 1 Function 0 to 1 --- 1 F102 0 (Disabled)
8601 Breaker Failure 1 Mode 0 to 1 --- 1 F157 0 (3-Pole)
8602 Breaker Failure 1 Source 0 to 5 --- 1 F167 0 (SRC 1)
8603 Breaker Failure 1 Amp Supervision 0 to 1 --- 1 F126 1 (Yes)
8604 Breaker Failure 1 Use Seal-In 0 to 1 --- 1 F126 1 (Yes)
8605 Breaker Failure 1 Three Pole Initiate 0 to 65535 --- 1 F300 0
8606 Breaker Failure 1 Block 0 to 65535 --- 1 F300 0
8607 Breaker Failure 1 Phase Amp Supv Pickup 0.001 to 30 pu 0.001 F001 1050
8608 Breaker Failure 1 Neutral Amp Supv Pickup 0.001 to 30 pu 0.001 F001 1050
8609 Breaker Failure 1 Use Timer 1 0 to 1 --- 1 F126 1 (Yes)
860A Breaker Failure 1 Timer 1 Pickup 0 to 65.535 s 0.001 F001 0
860B Breaker Failure 1 Use Timer 2 0 to 1 --- 1 F126 1 (Yes)
860C Breaker Failure 1 Timer 2 Pickup 0 to 65.535 s 0.001 F001 0
860D Breaker Failure 1 Use Timer 3 0 to 1 --- 1 F126 1 (Yes)
860E Breaker Failure 1 Timer 3 Pickup 0 to 65.535 s 0.001 F001 0
860F Breaker Failure 1 Breaker Status 1 Phase A/3P 0 to 65535 --- 1 F300 0
8610 Breaker Failure 1 Breaker Status 2 Phase A/3P 0 to 65535 --- 1 F300 0
8611 Breaker Failure 1 Breaker Test On 0 to 65535 --- 1 F300 0
8612 Breaker Failure 1 Phase Amp Hiset Pickup 0.001 to 30 pu 0.001 F001 1050
8613 Breaker Failure 1 Neutral Amp Hiset Pickup 0.001 to 30 pu 0.001 F001 1050
8614 Breaker Failure 1 Phase Amp Loset Pickup 0.001 to 30 pu 0.001 F001 1050
8615 Breaker Failure 1 Neutral Amp Loset Pickup 0.001 to 30 pu 0.001 F001 1050
8616 Breaker Failure 1 Loset Time 0 to 65.535 s 0.001 F001 0
8617 Breaker Failure 1 Trip Dropout Delay 0 to 65.535 s 0.001 F001 0
8618 Breaker Failure 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
8619 Breaker Failure 1 Events 0 to 1 --- 1 F102 0 (Disabled)
861A Breaker Failure 1 Phase A Initiate 0 to 65535 --- 1 F300 0
861B Breaker Failure 1 Phase B Initiate 0 to 65535 --- 1 F300 0
Table B–9: MODBUS MEMORY MAP (Sheet 31 of 55)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
