GE UR series

B-40 L60 Line Phase Comparison System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
861C Breaker Failure 1 Phase C Initiate 0 to 65535 --- 1 F300 0
861D Breaker Failure 1 Breaker Status 1 Phase B 0 to 65535 --- 1 F300 0
861E Breaker Failure 1 Breaker Status 1 Phase C 0 to 65535 --- 1 F300 0
861F Breaker Failure 1 Breaker Status 2 Phase B 0 to 65535 --- 1 F300 0
8620 Breaker Failure 1 Breaker Status 2 Phase C 0 to 65535 --- 1 F300 0
8621 ...Repeated for Breaker Failure 2
8642 ...Repeated for Breaker Failure 3
8663 ...Repeated for Breaker Failure 4
8684 ...Repeated for Breaker Failure 5
86A5 ...Repeated for Breaker Failure 6
FlexState Settings (Read/Write Setting)
8800 FlexState Parameters (256 items) --- --- --- F300 0
Digital Elements (Read/Write Setting) (48 modules)
8A00 Digital Element 1 Function 0 to 1 --- 1 F102 0 (Disabled)
8A01 Digital Element 1 Name --- --- --- F203 “Dig Element 1“
8A09 Digital Element 1 Input 0 to 65535 --- 1 F300 0
8A0A Digital Element 1 Pickup Delay 0 to 999999.999 s 0.001 F003 0
8A0C Digital Element 1 Reset Delay 0 to 999999.999 s 0.001 F003 0
8A0E Digital Element 1 Block 0 to 65535 --- 1 F300 0
8A0F Digital Element 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
8A10 Digital Element 1 Events 0 to 1 --- 1 F102 0 (Disabled)
8A11 Digital Element 1 Pickup LED 0 to 1 --- 1 F102 1 (Enabled)
8A12 Reserved (2 items) --- --- --- F001 0
8A14 ...Repeated for Digital Element 2
8A28 ...Repeated for Digital Element 3
8A3C ...Repeated for Digital Element 4
8A50 ...Repeated for Digital Element 5
8A64 ...Repeated for Digital Element 6
8A78 ...Repeated for Digital Element 7
8A8C ...Repeated for Digital Element 8
8AA0 ...Repeated for Digital Element 9
8AB4 ...Repeated for Digital Element 10
8AC8 ...Repeated for Digital Element 11
8ADC ...Repeated for Digital Element 12
8AF0 ...Repeated for Digital Element 13
8B04 ...Repeated for Digital Element 14
8B18 ...Repeated for Digital Element 15
8B2C ...Repeated for Digital Element 16
8B40 ...Repeated for Digital Element 17
8B54 ...Repeated for Digital Element 18
8B68 ...Repeated for Digital Element 19
8B7C ...Repeated for Digital Element 20
8B90 ...Repeated for Digital Element 21
8BA4 ...Repeated for Digital Element 22
8BB8 ...Repeated for Digital Element 23
8BCC ...Repeated for Digital Element 24
8BE0 ...Repeated for Digital Element 25
8BF4 ...Repeated for Digital Element 26
8C08 ...Repeated for Digital Element 27
8C1C ...Repeated for Digital Element 28
8C30 ...Repeated for Digital Element 29
8C44 ...Repeated for Digital Element 30
8C58 ...Repeated for Digital Element 31
8C6C ...Repeated for Digital Element 32
Table B–9: MODBUS MEMORY MAP (Sheet 32 of 55)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
