GE UR series

B-42 L60 Line Phase Comparison System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
9008 FlexElement™ 1 Direction 0 to 1 --- 1 F517 0 (OVER)
9009 FlexElement™ 1 Hysteresis 0.1 to 50 % 0.1 F001 30
900A FlexElement™ 1 Pickup -90 to 90 pu 0.001 F004 1000
900C FlexElement™ 1 DeltaT Units 0 to 2 --- 1 F518 0 (Milliseconds)
900D FlexElement™ 1 DeltaT 20 to 86400 --- 1 F003 20
900F FlexElement™ 1 Pickup Delay 0 to 65.535 s 0.001 F001 0
9010 FlexElement™ 1 Reset Delay 0 to 65.535 s 0.001 F001 0
9011 FlexElement™ 1 Block 0 to 65535 --- 1 F300 0
9012 FlexElement™ 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
9013 FlexElement™ 1 Events 0 to 1 --- 1 F102 0 (Disabled)
9014 ...Repeated for FlexElement™ 2
9028 ...Repeated for FlexElement™ 3
903C ...Repeated for FlexElement™ 4
9050 ...Repeated for FlexElement™ 5
9064 ...Repeated for FlexElement™ 6
9078 ...Repeated for FlexElement™ 7
908C ...Repeated for FlexElement™ 8
90A0 ...Repeated for FlexElement™ 9
90B4 ...Repeated for FlexElement™ 10
90C8 ...Repeated for FlexElement™ 11
90DC ...Repeated for FlexElement™ 12
90F0 ...Repeated for FlexElement™ 13
9104 ...Repeated for FlexElement™ 14
9118 ...Repeated for FlexElement™ 15
912C ...Repeated for FlexElement™ 16
Fault Report Settings (Read/Write Setting) (up to 5 modules)
9200 Fault Report 1 Source 0 to 5 --- 1 F167 0 (SRC 1)
9201 Fault Report 1 Trigger 0 to 65535 --- 1 F300 0
9202 Fault Report 1 Z1 Magnitude 0.01 to 250 ohms 0.01 F001 300
9203 Fault Report 1 Z1 Angle 25 to 90 degrees 1 F001 75
9204 Fault Report 1 Z0 Magnitude 0.01 to 650 ohms 0.01 F001 900
9205 Fault Report 1 Z0 Angle 25 to 90 degrees 1 F001 75
9206 Fault Report 1 Line Length Units 0 to 1 --- 1 F147 0 (km)
9207 Fault Report 1 Line Length 0 to 2000 0.1 F001 1000
9208 Fault Report 1 VT Substitution 0 to 2 --- 1 F270 0 (None)
9208 Fault Report 1 System Z0 Magnitude 0.01 to 650.00 ohms 0.01 F001 900
9208 Fault Report 1 System Z0 Angle 25 to 90 degrees 1 F001 75
920B ...Repeated for Fault Report 2
9216 ...Repeated for Fault Report 3
9221 ...Repeated for Fault Report 4
922C ...Repeated for Fault Report 5
dcmA Outputs (Read/Write Setting) (24 modules)
9300 dcmA Output 1 Source 0 to 65535 --- 1 F600 0
9301 dcmA Output 1 Range 0 to 2 --- 1 F522 0 (–1 to 1 mA)
9302 dcmA Output 1 Minimum –90 to 90 pu 0.001 F004 0
9304 dcmA Output 1 Maximum –90 to 90 pu 0.001 F004 1000
9306 ...Repeated for dcmA Output 2
930C ...Repeated for dcmA Output 3
9312 ...Repeated for dcmA Output 4
9318 ...Repeated for dcmA Output 5
931E ...Repeated for dcmA Output 6
9324 ...Repeated for dcmA Output 7
932A ...Repeated for dcmA Output 8
9330 ...Repeated for dcmA Output 9
Table B–9: MODBUS MEMORY MAP (Sheet 34 of 55)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
