B-46 L60 Line Phase Comparison System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
A80B Digital Counter 1 Up 0 to 65535 --- 1 F300 0
A80C Digital Counter 1 Down 0 to 65535 --- 1 F300 0
A80D Digital Counter 1 Preset –2147483647 to
2147483647
--- 1 F004 0
A80F Digital Counter 1 Compare –2147483647 to
2147483647
--- 1 F004 0
A811 Digital Counter 1 Reset 0 to 65535 --- 1 F300 0
A812 Digital Counter 1 Freeze/Reset 0 to 65535 --- 1 F300 0
A813 Digital Counter 1 Freeze/Count 0 to 65535 --- 1 F300 0
A814 Digital Counter 1 Set To Preset 0 to 65535 --- 1 F300 0
A815 Reserved (11 items) --- --- --- F001 0
A820 ...Repeated for Digital Counter 2
A840 ...Repeated for Digital Counter 3
A860 ...Repeated for Digital Counter 4
A880 ...Repeated for Digital Counter 5
A8A0 ...Repeated for Digital Counter 6
A8C0 ...Repeated for Digital Counter 7
A8E0 ...Repeated for Digital Counter 8
IEC 61850 received analog settings (read/write)
AA00 IEC 61850 GOOSE analog 1 default value –1000000 to 1000000 --- 0.001 F060 1000
AA02 IEC 61850 GOOSE analog input 1 mode 0 to 1 --- 1 F491 0 (Default Value)
AA03 IEC 61850 GOOSE analog input 1 units --- --- --- F207 (none)
AA05 IEC 61850 GOOSE analog input 1 per-unit base 0 to 999999999.999 --- 0.001 F060 1
AA07 ...Repeated for IEC 61850 GOOSE analog input 2
AA0E ...Repeated for IEC 61850 GOOSE analog input 3
AA15 ...Repeated for IEC 61850 GOOSE analog input 4
AA1C ...Repeated for IEC 61850 GOOSE analog input 5
AA23 ...Repeated for IEC 61850 GOOSE analog input 6
AA2A ...Repeated for IEC 61850 GOOSE analog input 7
AA31 ...Repeated for IEC 61850 GOOSE analog input 8
AA38 ...Repeated for IEC 61850 GOOSE analog input 9
AA3F ...Repeated for IEC 61850 GOOSE analog input 10
AA46 ...Repeated for IEC 61850 GOOSE analog input 11
AA4D ...Repeated for IEC 61850 GOOSE analog input 12
AA54 ...Repeated for IEC 61850 GOOSE analog input 13
AA5B ...Repeated for IEC 61850 GOOSE analog input 14
AA62 ...Repeated for IEC 61850 GOOSE analog input 15
AA69 ...Repeated for IEC 61850 GOOSE analog input 16
IEC 61850 GOOSE/GSSE Configuration (Read/Write Setting)
AA80 Default GOOSE/GSSE Update Time 1 to 60 s 1 F001 60
AA81 IEC 61850 GSSE Function (GsEna) 0 to 1 --- 1 F102 1 (Enabled)
AA82 IEC 61850 GSSE ID --- --- --- F209 “GSSEOut”
AAA3 IEC 61850 GOOSE Function (GoEna) 0 to 1 --- 1 F102 0 (Disabled)
AAA4 IEC 61850 GSSE Destination MAC Address --- --- --- F072 0
AAA7 IEC 61850 Standard GOOSE ID --- --- --- F209 “GOOSEOut”
AAC8 IEC 61850 Standard GOOSE Destination MAC Address --- --- --- F072 0
AACB IEC 61850 GOOSE VLAN Transmit Priority 0 to 7 --- 1 F001 4
AACC IEC 61850 GOOSE VLAN ID 0 to 4095 --- 1 F001 0
AACD IEC 61850 GOOSE ETYPE APPID 0 to 16383 --- 1 F001 0
AACE Reserved (2 items) 0 to 1 --- 1 F001 0
IEC 61850 Server Configuration (Read/Write Settings/Commands)
AAD0 TCP Port Number for the IEC 61850 / MMS Protocol 1 to 65535 --- 1 F001 102
AAD1 IEC 61850 Logical Device Name --- --- --- F213 “IECName”
AAE1 IEC 61850 Logical Device Instance --- --- --- F213 “LDInst”
AAF1 IEC 61850 LPHD Location --- --- --- F204 “Location”
Table B–9: MODBUS MEMORY MAP (Sheet 38 of 55)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
