GE Multilin L60 Line Phase Comparison System B-47
APPENDIX B B.4 MEMORY MAPPING
B
AB19 Include non-IEC 61850 Data 0 to 1 --- 1 F102 0 (Disabled)
AB1A IEC 61850 Server Data Scanning Function 0 to 1 --- 1 F102 0 (Disabled)
AB1B Reserved (15 items)
IEC 61850 XCBR configuration (read/write settings)
AB24 Operand for IEC 61850 XCBR1.ST.Loc status 0 to 65535 --- 1 F300 0
AB25 Command to clear XCBR1 OpCnt (operation counter) 0 to 1 --- 1 F126 0 (No)
AB26 Operand for IEC 61850 XCBR2.ST.Loc status 0 to 65535 --- 1 F300 0
AB27 Command to clear XCBR2 OpCnt (operation counter) 0 to 1 --- 1 F126 0 (No)
AB28 Operand for IEC 61850 XCBR3.ST.Loc status 0 to 65535 --- 1 F300 0
AB29 Command to clear XCBR3 OpCnt (operation counter) 0 to 1 --- 1 F126 0 (No)
AB2A Operand for IEC 61850 XCBR4.ST.Loc status 0 to 65535 --- 1 F300 0
AB2B Command to clear XCBR4 OpCnt (operation counter) 0 to 1 --- 1 F126 0 (No)
AB2C Operand for IEC 61850 XCBR5.ST.Loc status 0 to 65535 --- 1 F300 0
AB2D Command to clear XCBR5 OpCnt (operation counter) 0 to 1 --- 1 F126 0 (No)
AB2E Operand for IEC 61850 XCBR6.ST.Loc status 0 to 65535 --- 1 F300 0
AB2F Command to clear XCBR6 OpCnt (operation counter) 0 to 1 --- 1 F126 0 (No)
IEC 61850 LN name prefixes (read/write settings)
AB30 IEC 61850 logical node LPHD1 name prefix 0 to 65534 --- 1 F206 (none)
AB33 IEC 61850 logical node PIOCx name prefix (72 items) 0 to 65534 --- 1 F206 (none)
AC0B IEC 61850 logical node PTOCx name prefix (24 items) 0 to 65534 --- 1 F206 (none)
AC53 IEC 61850 logical node PTUVx name prefix (13 items) 0 to 65534 --- 1 F206 (none)
AC7A IEC 61850 logical node PTOVx name prefix (10 items) 0 to 65534 --- 1 F206 (none)
AC98 IEC 61850 logical node PDISx name prefix (10 items) 0 to 65534 --- 1 F206 (none)
ACB6 IEC 61850 logical node RBRFx name prefix (24 items) 0 to 65534 --- 1 F206 (none)
ACFE IEC 61850 logical node RPSBx name prefix 0 to 65534 --- 1 F206 (none)
AD01 IEC 61850 logical node RRECx name prefix (6 items) 0 to 65534 --- 1 F206 (none)
AD13 IEC 61850 logical node MMXUx name prefix (6 items) 0 to 65534 --- 1 F206 (none)
AD25 IEC 61850 logical node GGIOx name prefix (4 items) 0 to 65534 --- 1 F206 (none)
AD31 IEC 61850 logical node RFLOx name prefix (5 items) 0 to 65534 --- 1 F206 (none)
AD40 IEC 61850 logical node XCBRx name prefix (6 items) 0 to 65534 --- 1 F206 (none)
AD52 IEC 61850 logical node PTRCx name prefix (6 items) 0 to 65534 --- 1 F206 (none)
AD64 IEC 61850 logical node PDIFx name prefix (6 items) 0 to 65534 --- 1 F206 (none)
AD70 IEC 61850 logical node MMXNx name prefix (6 items) 0 to 65534 --- 1 F206 (none)
ADDF IEC 61850 logical node CSWIx name prefix (6 items) 0 to 65534 --- 1 F206 (none)
AE39 IEC 61850 logical node XSWIx name prefix (6 items) 0 to 65534 --- 1 F206 (none)
IEC 61850 XSWI configuration (read/write settings)
AECF Operand for IEC 61850 XSWI1.ST.Loc status 0 to 65535 --- 1 F300 0
AED0 Command to clear XSWI1 OpCnt (operation counter) 0 to 1 --- 1 F126 0 (No)
AED1 Repeated for IEC 61850 XSWI2
AED3 Repeated for IEC 61850 XSWI3
AED5 Repeated for IEC 61850 XSWI4
AED7 Repeated for IEC 61850 XSWI5
AED9 Repeated for IEC 61850 XSWI6
AEDB Repeated for IEC 61850 XSWI7
AEDD Repeated for IEC 61850 XSWI8
AEDF Repeated for IEC 61850 XSWI9
AEE1 Repeated for IEC 61850 XSWI10
AEE3 Repeated for IEC 61850 XSWI11
AEE5 Repeated for IEC 61850 XSWI12
AEE7 Repeated for IEC 61850 XSWI13
AEE9 Repeated for IEC 61850 XSWI14
AEEB Repeated for IEC 61850 XSWI15
AEED Repeated for IEC 61850 XSWI16
AEEF Repeated for IEC 61850 XSWI17
Table B–9: MODBUS MEMORY MAP (Sheet 39 of 55)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
