B.4 MEMORY MAPPING APPENDIX B
B
AEF1 Repeated for IEC 61850 XSWI18
AEF3 Repeated for IEC 61850 XSWI19
AEF5 Repeated for IEC 61850 XSWI20
AEF7 Repeated for IEC 61850 XSWI21
AEF9 Repeated for IEC 61850 XSWI22
AEFB Repeated for IEC 61850 XSWI23
AEFD Repeated for IEC 61850 XSWI24
IEC 61850 GGIO4 general analog configuration settings (read/write)
AF00 Number of analog points in GGIO4 4 to 32 --- 4 F001 4
IEC 61850 GGIO4 analog input points configuration settings (read/write)
AF10 IEC 61850 GGIO4 analog input 1 value --- --- --- F600 0
AF11 IEC 61850 GGIO4 analog input 1 deadband 0.001 to 100 % 0.001 F003 100000
AF13 IEC 61850 GGIO4 analog input 1 minimum –1000000000000 to
1000000000000
--- 0.001 F060 0
AF15 IEC 61850 GGIO4 analog input 1 maximum –1000000000000 to
1000000000000
--- 0.001 F060 1000000
AF17 ...Repeated for IEC 61850 GGIO4 analog input 2
AF1E ...Repeated for IEC 61850 GGIO4 analog input 3
AF25 ...Repeated for IEC 61850 GGIO4 analog input 4
AF2C ...Repeated for IEC 61850 GGIO4 analog input 5
AF33 ...Repeated for IEC 61850 GGIO4 analog input 6
AF3A ...Repeated for IEC 61850 GGIO4 analog input 7
AF41 ...Repeated for IEC 61850 GGIO4 analog input 8
AF48 ...Repeated for IEC 61850 GGIO4 analog input 9
AF4F ...Repeated for IEC 61850 GGIO4 analog input 10
AF56 ...Repeated for IEC 61850 GGIO4 analog input 11
AF5D ...Repeated for IEC 61850 GGIO4 analog input 12
AF64 ...Repeated for IEC 61850 GGIO4 analog input 13
AF6B ...Repeated for IEC 61850 GGIO4 analog input 14
AF72 ...Repeated for IEC 61850 GGIO4 analog input 15
AF79 ...Repeated for IEC 61850 GGIO4 analog input 16
AF80 ...Repeated for IEC 61850 GGIO4 analog input 17
AF87 ...Repeated for IEC 61850 GGIO4 analog input 18
AF8E ...Repeated for IEC 61850 GGIO4 analog input 19
AF95 ...Repeated for IEC 61850 GGIO4 analog input 20
AF9C ...Repeated for IEC 61850 GGIO4 analog input 21
AFA3 ...Repeated for IEC 61850 GGIO4 analog input 22
AFAA ...Repeated for IEC 61850 GGIO4 analog input 23
AFB1 ...Repeated for IEC 61850 GGIO4 analog input 24
AFB8 ...Repeated for IEC 61850 GGIO4 analog input 25
AFBF ...Repeated for IEC 61850 GGIO4 analog input 26
AFC6 ...Repeated for IEC 61850 GGIO4 analog input 27
AFCD ...Repeated for IEC 61850 GGIO4 analog input 28
AFD4 ...Repeated for IEC 61850 GGIO4 analog input 29
AFDB ...Repeated for IEC 61850 GGIO4 analog input 30
AFE2 ...Repeated for IEC 61850 GGIO4 analog input 31
AFE9 ...Repeated for IEC 61850 GGIO4 analog input 32
IEC 61850 Logical Node Name Prefixes (Read/Write Setting)
AB30 IEC 61850 Logical Node LPHD1 Name Prefix 0 to 65534 --- 1 F206 (None)
AB33 IEC 61850 Logical Node PIOCx Name Prefix (72 items) 0 to 65534 --- 1 F206 (None)
AC0B IEC 61850 Logical Node PTOCx Name Prefix (24 items) 0 to 65534 --- 1 F206 (None)
AC53 IEC 61850 Logical Node PTUVx Name Prefix (12 items) 0 to 65534 --- 1 F206 (None)
AC77 IEC 61850 Logical Node PTOVx Name Prefix (8 items) 0 to 65534 --- 1 F206 (None)
AC8F IEC 61850 Logical Node PDISx Name Prefix (10 items) 0 to 65534 --- 1 F206 (None)
ACAD IEC 61850 Logical Node RRBFx Name Prefix (24 items) 0 to 65534 --- 1 F206 (None)
Table B–9: MODBUS MEMORY MAP (Sheet 40 of 55)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
