GE UR series

GE Multilin L60 Line Phase Comparison System B-65
APPENDIX B B.4 MEMORY MAPPING
B
F082
ENUMERATION: AUTORECLOSE SINGLE-PHASE /
THREE-PHASE BREAKER SEQUENCE
0 = 1, 1 = 2, 2 = 1 & 2, 3 = 1 – 2, 4 = 2 – 1
F083
ENUMERATION: SELECTOR MODES
0 = Time-Out, 1 = Acknowledge
F084
ENUMERATION: SELECTOR POWER UP
0 = Restore, 1 = Synchronize, 2 = Sync/Restore
F085
ENUMERATION: POWER SWING SHAPE
0 = Mho Shape, 1 = Quad Shape
F086
ENUMERATION: DIGITAL INPUT DEFAULT STATE
0 = Off, 1 = On, 2= Latest/Off, 3 = Latest/On
F087
ENUMERATION: 87PC OSCILLOGRAPHY
0 = Basic, 1 = Minimum, 2 = Enhanced, 3 = Maximum
F088
ENUMERATION: 87PC PHASE COMPARISON SCHEME
SELECTION
F089
ENUMERATION: 87PC SIGNAL SOURCE
1 = One Source Current, 2 = Two Source Currents
F090
ENUMERATION: LATCHING OUTPUT TYPE
0 = Operate-dominant, 1 = Reset-dominant
F100
ENUMERATION: VT CONNECTION TYPE
0 = Wye; 1 = Delta
F101
ENUMERATION: MESSAGE DISPLAY INTENSITY
0 = 25%, 1 = 50%, 2 = 75%, 3 = 100%
F102
ENUMERATION: DISABLED/ENABLED
0 = Disabled; 1 = Enabled
F103
ENUMERATION: CURVE SHAPES
F104
ENUMERATION: RESET TYPE
0 = Instantaneous, 1 = Timed, 2 = Linear
F105
ENUMERATION: LOGIC INPUT
0 = Disabled, 1 = Input 1, 2 = Input 2
F106
ENUMERATION: PHASE ROTATION
0 = ABC, 1 = ACB
F108
ENUMERATION: OFF/ON
0 = Off, 1 = On
F109
ENUMERATION: CONTACT OUTPUT OPERATION
0 = Self-reset, 1 = Latched, 2 = Disabled
value scheme
02TL-TR-SPC-2FC
1 2TL-BL-SPC-2FC
2 2TL-UB-DPC-2FC
3 2TL-TR-DPC-3FC
4 2TL-BL-DPC-3FC
53TL-TR-SPC-2FC
6 3TL-BL-SPC-2FC
7 3TL-TR-DPC-3FC
8 3TL-BL-DPC-3FC
bitmask curve shape bitmask curve shape
0 IEEE Mod Inv 9 IAC Inverse
1 IEEE Very Inv 10 IAC Short Inv
2 IEEE Ext Inv 11 I2t
3 IEC Curve A 12 Definite Time
4 IEC Curve B 13 FlexCurve™ A
5 IEC Curve C 14 FlexCurve™ B
6 IEC Short Inv 15 FlexCurve™ C
7 IAC Ext Inv 16 FlexCurve™ D
8 IAC Very Inv
