B.4 MEMORY MAPPING APPENDIX B
B
F110
ENUMERATION: CONTACT OUTPUT LED CONTROL
0 = Trip, 1 = Alarm, 2 = None
F111
ENUMERATION: UNDERVOLTAGE CURVE SHAPES
0 = Definite Time, 1 = Inverse Time
F112
ENUMERATION: RS485 BAUD RATES
F113
ENUMERATION: PARITY
0 = None, 1 = Odd, 2 = Even
F114
ENUMERATION: IRIG-B SIGNAL TYPE
0 = None, 1 = DC Shift, 2 = Amplitude Modulated
F115
ENUMERATION: BREAKER STATUS
0 = Auxiliary A, 1 = Auxiliary B
F116
ENUMERATION: NEUTRAL OVERVOLTAGE CURVES
0 = Definite Time, 1 = FlexCurve™ A, 2 = FlexCurve™ B,
3 = FlexCurve™ C
F117
ENUMERATION: NUMBER OF OSCILLOGRAPHY RECORDS
0 = 1×72 cycles, 1 = 3×36 cycles, 2 = 7×18 cycles, 3 = 15×9 cycles
F118
ENUMERATION: OSCILLOGRAPHY MODE
0 = Automatic Overwrite, 1 = Protected
F119
ENUMERATION: FLEXCURVE™ PICKUP RATIOS
F120
ENUMERATION: DISTANCE SHAPE
0 = Mho, 1 = Quad
F122
ENUMERATION: ELEMENT INPUT SIGNAL TYPE
0 = Phasor, 1 = RMS
F123
ENUMERATION: CT SECONDARY
0 = 1 A, 1 = 5 A
bitmask value bitmask value bitmask value
0 300 4 9600 8 115200
1 1200 5 19200 9 14400
2 2400 6 38400 10 28800
3 4800 7 57600 11 33600
mask value mask value mask value mask value
00.00300.88602.90905.90
10.05310.90613.00916.00
20.10320.91623.10926.50
30.15330.92633.20937.00
40.20340.93643.30947.50
50.25350.94653.40958.00
60.30360.95663.50968.50
70.35370.96673.60979.00
80.40380.97683.70989.50
90.45390.98693.809910.00
10 0.48 40 1.03 70 3.90 100 10.50
