F124
ENUMERATION: LIST OF ELEMENTS
bitmask element
0 Phase Instantaneous Overcurrent 1
1 Phase Instantaneous Overcurrent 2
2 Phase Instantaneous Overcurrent 3
3 Phase Instantaneous Overcurrent 4
4 Phase Instantaneous Overcurrent 5
5 Phase Instantaneous Overcurrent 6
6 Phase Instantaneous Overcurrent 7
7 Phase Instantaneous Overcurrent 8
8 Phase Instantaneous Overcurrent 9
9 Phase Instantaneous Overcurrent 10
10 Phase Instantaneous Overcurrent 11
11 Phase Instantaneous Overcurrent 12
16 Phase Time Overcurrent 1
17 Phase Time Overcurrent 2
18 Phase Time Overcurrent 3
19 Phase Time Overcurrent 4
20 Phase Time Overcurrent 5
21 Phase Time Overcurrent 6
24 Phase Directional Overcurrent 1
25 Phase Directional Overcurrent 2
32 Neutral Instantaneous Overcurrent 1
33 Neutral Instantaneous Overcurrent 2
34 Neutral Instantaneous Overcurrent 3
35 Neutral Instantaneous Overcurrent 4
36 Neutral Instantaneous Overcurrent 5
37 Neutral Instantaneous Overcurrent 6
38 Neutral Instantaneous Overcurrent 7
39 Neutral Instantaneous Overcurrent 8
40 Neutral Instantaneous Overcurrent 9
41 Neutral Instantaneous Overcurrent 10
42 Neutral Instantaneous Overcurrent 11
43 Neutral Instantaneous Overcurrent 12
48 Neutral Time Overcurrent 1
49 Neutral Time Overcurrent 2
50 Neutral Time Overcurrent 3
51 Neutral Time Overcurrent 4
52 Neutral Time Overcurrent 5
53 Neutral Time Overcurrent 6
56 Neutral Directional Overcurrent 1
57 Neutral Directional Overcurrent 2
60 Negative Sequence Directional Overcurrent 1
61 Negative Sequence Directional Overcurrent 2
64 Ground Instantaneous Overcurrent 1
65 Ground Instantaneous Overcurrent 2
66 Ground Instantaneous Overcurrent 3
67 Ground Instantaneous Overcurrent 4
68 Ground Instantaneous Overcurrent 5
69 Ground Instantaneous Overcurrent 6
70 Ground Instantaneous Overcurrent 7
71 Ground Instantaneous Overcurrent 8
72 Ground Instantaneous Overcurrent 9
73 Ground Instantaneous Overcurrent 10
74 Ground Instantaneous Overcurrent 11
75 Ground Instantaneous Overcurrent 12
80 Ground Time Overcurrent 1
81 Ground Time Overcurrent 2
82 Ground Time Overcurrent 3
83 Ground Time Overcurrent 4
84 Ground Time Overcurrent 5
85 Ground Time Overcurrent 6
96 Negative Sequence Instantaneous Overcurrent 1
97 Negative Sequence Instantaneous Overcurrent 2
101 Opposite Phase Rotation
112 Negative Sequence Time Overcurrent 1
113 Negative Sequence Time Overcurrent 2
120 Negative Sequence Overvoltage
121 Wattmetric Zero-Sequence Directional 1
122 Wattmetric Zero-Sequence Directional 2
140 Auxiliary Undervoltage 1
144 Phase Undervoltage 1
145 Phase Undervoltage 2
148 Auxiliary Overvoltage 1
152 Phase Overvoltage 1
156 Neutral Overvoltage 1
161 Phase Distance Zone 2
168 Line Pickup
172 Ground Distance Zone 1
173 Ground Distance Zone 2
174 Ground Distance Zone 3
180 Load Enchroachment
185 PUTT Pilot Scheme
190 Power Swing Detect
224 SRC1 VT Fuse Failure
225 SRC2 VT Fuse Failure
226 SRC3 VT Fuse Failure
227 SRC4 VT Fuse Failure
228 SRC5 VT Fuse Failure
229 SRC6 VT Fuse Failure
232 SRC1 50DD (Disturbance Detection)
233 SRC2 50DD (Disturbance Detection)
234 SRC3 50DD (Disturbance Detection)
235 SRC4 50DD (Disturbance Detection)
245 Continuous Monitor
246 CT Failure
280 Breaker Failure 1
281 Breaker Failure 2
288 Breaker Arcing Current 1
289 Breaker Arcing Current 2
290 Breaker Arcing Current 3
291 Breaker Arcing Current 4
292 Breaker Arcing Current 5
293 Breaker Arcing Current 6
