GE UR series

B-70 L60 Line Phase Comparison System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
F127
ENUMERATION: LATCHED OR SELF-RESETTING
0 = Latched, 1 = Self-Reset
F128
ENUMERATION: CONTACT INPUT THRESHOLD
0 = 17 V DC, 1 = 33 V DC, 2 = 84 V DC, 3 = 166 V DC
F129
ENUMERATION: FLEXLOGIC TIMER TYPE
0 = millisecond, 1 = second, 2 = minute
F130
ENUMERATION: SIMULATION MODE
0 = Off. 1 = Pre-Fault, 2 = Fault, 3 = Post-Fault
F131
ENUMERATION: FORCED CONTACT OUTPUT STATE
0 = Disabled, 1 = Energized, 2 = De-energized, 3 = Freeze
F133
ENUMERATION: PROGRAM STATE
0 = Not Programmed, 1 = Programmed
F134
ENUMERATION: PASS/FAIL
0 = Fail, 1 = OK, 2 = n/a
F135
ENUMERATION: GAIN CALIBRATION
0 = 0x1, 1 = 1x16
F136
ENUMERATION: NUMBER OF OSCILLOGRAPHY RECORDS
0 = 31 x 8 cycles, 1 = 15 x 16 cycles, 2 = 7 x 32 cycles
3 = 3 x 64 cycles, 4 = 1 x 128 cycles
F137
ENUMERATION: USER-PROGRAMMABLE PUSHBUTTON
FUNCTION
0 = Disabled, 1 = Self-Reset, 2 = Latched
F138
ENUMERATION: OSCILLOGRAPHY FILE TYPE
0 = Data File, 1 = Configuration File, 2 = Header File
F140
ENUMERATION: CURRENT, SENS CURRENT, VOLTAGE,
DISABLED
0 = Disabled, 1 = Current 46 A, 2 = Voltage 280 V,
3 = Current 4.6 A, 4 = Current 2 A, 5 = Notched 4.6 A,
6 = Notched 2 A
F141
ENUMERATION: SELF TEST ERRORS
bitmask error
0 Any Self Tests
1 Maintenance Alert
8 RRTD Communications Failure
10 FlexLogic Error Token
11 Equipment Mismatch
13 Unit Not Programmed
14 System Exception
15 Maintenance Alert
16 Ethernet Switch Failure
17 Maintenance Alert
18 Maintenance Alert
19 Maintenance Alert
20 Maintenance Alert
21 Maintenance Alert
22 Temperature Monitor
27 Remote Device Off
28 Direct Device Off
29 Maintenance Alert
30 Any Minor Error
31 Any Major Error
32 DSP Error
33 No DSP Interrupts
34 Unit Not Calibrated
35 EEPROM Data Error
36 SRAM Data Error
37 Program Memory
38 Watchdog Error
39 Low On Memory
40 Prototype Firmware
41 Module Failure 01
42 Module Failure 02
43 Module Failure 03
44 Module Failure 04
45 Module Failure 05
46 Module Failure 06
47 Module Failure 07
48 Module Failure 08
49 Module Failure 09
50 Incompatible H/W
52 Brick Trouble
53 Module Failure 10
54 Module Failure 11
