GE UR series

GE Multilin L60 Line Phase Comparison System B-71
APPENDIX B B.4 MEMORY MAPPING
B
F142
ENUMERATION: EVENT RECORDER ACCESS FILE TYPE
0 = All Record Data, 1 = Headers Only, 2 = Numeric Event Cause
F143
UR_UINT32: 32 BIT ERROR CODE (F141 specifies bit number)
A bit value of 0 = no error, 1 = error
F144
ENUMERATION: FORCED CONTACT INPUT STATE
0 = Disabled, 1 = Open, 2 = Closed
F145
ENUMERATION: ALPHABET LETTER
F146
ENUMERATION: MISCELLANEOUS EVENT CAUSES
F147
ENUMERATION: LINE LENGTH UNITS
0 = km, 1 = miles
F148
ENUMERATION: FAULT TYPE
F149
ENUMERATION: 87PC PHASE COMPARISON SCHEME
SELECTION
F150
ENUMERATION: 87PC PHASE COMPARISON SCHEME
SIGNAL SELECTION
0 = MIXED I_2 - K*I_1, 1 = 3I_0
55 Maintenance Alert
56 Maintenance Alert
bitmask type bitmask type bitmask type bitmask type
0 null 7 G 14 N 21 U
1A 8H 15O 22V
2B 9 I 16P 23W
3 C 10 J 17 Q 24 X
4D 11K 18R 25Y
5 E 12 L 19 S 26 Z
6F 13M 20T
bitmask definition
0 Events Cleared
1 Oscillography Triggered
2 Date/time Changed
3 Default Settings Loaded
4 Test Mode Forcing On
5 Test Mode Forcing Off
6 Power On
7 Power Off
8 Relay In Service
9 Relay Out Of Service
10 Watchdog Reset
11 Oscillography Clear
12 Reboot Command
13 Led Test Initiated
14 Flash Programming
15 Fault Report Trigger
bitmask error
16 User Programmable Fault Report Trigger
17 Corrupt CT/VT module Program
18 Reload CT/VT module Settings
19 CT/VT Module Hardware Error
20 Ethernet Port 1 Offline
21 Ethernet Port 2 Offline
22 Ethernet Port 3 Offline
23 Ethernet Port 4 Offline
24 Ethernet Port 5 Offline
25 Ethernet Port 6 Offline
26 Test Mode Isolated
27 Test Mode Forcible
28 Test Mode Disabled
29 Temperature Warning On
30 Temperature Warning Off
31 Unauthorized Access
32 System Integrity Recovery
bitmask fault type bitmask fault type
0NA 6AC
1AG 7ABG
2BG 8BCG
3CG 9ACG
4 AB 10 ABC
5BC 11ABCG
bitmask phase comp scheme
0 2TL-PT-DPC-3FC
1 2TL-BL-DPC-3FC
2 2TL-PT-SPC-2FC
3 2TL-BL-SPC-2FC
4 2TL-BL-DPC-2FC
5 3TL-PT-SPC-3FC
bitmask definition
