B-72 L60 Line Phase Comparison System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
F151
ENUMERATION: RTD SELECTION
F152
ENUMERATION: SETTING GROUP
0 = Active Group, 1 = Group 1, 2 = Group 2, 3 = Group 3
4 = Group 4, 5 = Group 5, 6 = Group 6
F153
ENUMERATION: DISTANCE TRANSFORMER CONNECTION
F154
ENUMERATION: DISTANCE DIRECTION
0 = Forward, 1 = Reverse, 2 = Non-Directional
F155
ENUMERATION: REMOTE DEVICE STATE
0 = Offline, 1 = Online
F156
ENUMERATION: REMOTE INPUT BIT PAIRS
F157
ENUMERATION: BREAKER MODE
0 = 3-Pole, 1 = 1-Pole
F158
ENUMERATION: SCHEME CALIBRATION TEST
0 = Normal, 1 = Symmetry 1, 2 = Symmetry 2, 3 = Delay 1
4 = Delay 2
F159
ENUMERATION: BREAKER AUX CONTACT KEYING
0 = 52a, 1 = 52b, 2 = None
bitmask RTD# bitmask RTD# bitmask RTD#
0 NONE 17 RTD 17 33 RTD 33
1 RTD 1 18 RTD 18 34 RTD 34
2 RTD 2 19 RTD 19 35 RTD 35
3 RTD 3 20 RTD 20 36 RTD 36
4 RTD 4 21 RTD 21 37 RTD 37
5 RTD 5 22 RTD 22 38 RTD 38
6 RTD 6 23 RTD 23 39 RTD 39
7 RTD 7 24 RTD 24 40 RTD 40
8 RTD 8 25 RTD 25 41 RTD 41
9 RTD 9 26 RTD 26 42 RTD 42
10 RTD 10 27 RTD 27 43 RTD 43
11 RTD 11 28 RTD 28 44 RTD 44
12 RTD 12 29 RTD 29 45 RTD 45
13 RTD 13 30 RTD 30 46 RTD 46
14 RTD 14 31 RTD 31 47 RTD 47
15 RTD 15 32 RTD 32 48 RTD 48
16 RTD 16
bitmask type bitmask type bitmask type
0None 5 Dy9 10 Yd7
1 Dy1 6 Dy11 11 Yd9
2 Dy3 7 Yd1 12 Yd11
3Dy5 8 Yd3
4Dy7 9 Yd5
bitmask value bitmask value
0 NONE 35 UserSt-3
1 DNA-1 36 UserSt-4
2 DNA-2 37 UserSt-5
3 DNA-3 38 UserSt-6
4 DNA-4 39 UserSt-7
5 DNA-5 40 UserSt-8
6 DNA-6 41 UserSt-9
7 DNA-7 42 UserSt-10
8 DNA-8 43 UserSt-11
9 DNA-9 44 UserSt-12
10 DNA-10 45 UserSt-13
11 DNA-11 46 UserSt-14
12 DNA-12 47 UserSt-15
13 DNA-13 48 UserSt-16
14 DNA-14 49 UserSt-17
15 DNA-15 50 UserSt-18
16 DNA-16 51 UserSt-19
17 DNA-17 52 UserSt-20
18 DNA-18 53 UserSt-21
19 DNA-19 54 UserSt-22
20 DNA-20 55 UserSt-23
21 DNA-21 56 UserSt-24
22 DNA-22 57 UserSt-25
23 DNA-23 58 UserSt-26
24 DNA-24 59 UserSt-27
25 DNA-25 60 UserSt-28
26 DNA-26 61 UserSt-29
27 DNA-27 62 UserSt-30
28 DNA-28 63 UserSt-31
29 DNA-29 64 UserSt-32
30 DNA-30 65 Dataset Item 1
31 DNA-31 66 Dataset Item 2
32 DNA-32 67 Dataset Item 3
33 UserSt-1 ↓↓
34 UserSt-2 128 Dataset Item 64
