l) PMU RECORDING
PATH: SETTINGS  SYSTEM SETUP  PHASOR...  PHASOR MEASUREMENT UNIT 1  PMU 1 RECORDING
Each logical phasor measurement unit (PMU) is associated with a recorder. The triggering condition is programmed via the
PMU 1 TRIGGERING menu. The recorder works with polar values using resolution as in the PMU actual values.
 PMU 1
 RECORDING
PMU 1 RECORDING
RATE: 10/sec
Range: 1, 2, 4, 5, 10, 12, 15, 20, 25, 30, 50, or 60 times
per second
MESSAGE
PMU 1 NO OF TIMED
RECORDS: 10
Range: 2 to 128 in steps of 1
MESSAGE
PMU 1 TRIGGER MODE:
Automatic Overwrite
Range: Automatic Overwrite, Protected
MESSAGE
PMU 1 TIMED TRIGGER
POSITION: 10%
Range: 1 to 50% in steps of 1
MESSAGE
PMU 1 REC PHS-1:
PMU 1 V1
Range: available synchrophasor values
MESSAGE
PMU 1 REC PHS-1
NM: GE-UR-PMU-V1
Range: 16 character ASCII string
↓
MESSAGE
PMU 1 REC PHS-14:
Off
Range: available synchrophasor values
MESSAGE
PMU 1 REC PHS-14
NM: GE-UR-PMU-PHS-14
Range: 16 character ASCII string
MESSAGE
PMU 1 REC A-CH-1:
Off
Range: available FlexAnalog values
MESSAGE
PMU 1 REC A-CH-1
NM: AnalogChannel1
Range: 16 character ASCII string
↓
MESSAGE
PMU 1 REC A-CH-8:
Off
Range: available FlexAnalog values
MESSAGE
PMU 1 REC A-CH-8
NM: AnalogChannel8
Range: 16 character ASCII string
MESSAGE
PMU 1 REC D-CH-1:
Off
Range: FlexLogic™ operand
MESSAGE
PMU 1 REC D-CH-1
NM: DigitalChannel1
Range: 16 character ASCII string
↓
MESSAGE
PMU 1 REC D-CH-16:
Off
Range: FlexLogic™ operand
MESSAGE
PMU 1 REC D-CH-16
NM: DigitalChannel16
Range: 16 character ASCII string
