GE Multilin T60 Transformer Protection System 2-7
2 PRODUCT DESCRIPTION 2.1 INTRODUCTION
2
The order codes for the reduced size vertical mount units with the process bus module are shown below.
Table 2–6: T60 ORDER CODES (REDUCED SIZE VERTICAL UNITS WITH PROCESS BUS)
T60 - * ** - * * * - F ** - H ** - M ** - P/R ** Reduced Size Vertical Mount (see note regarding P/R slot below)
BASE UNIT T60 | | | | | | | | | Base Unit
CPU E | | | | | | | | RS485 and RS485
J | | | | | | | | RS485, multi-mode ST 100Base-FX and 10/100Base-T
K | | | | | | | | RS485, multi-mode ST redundant 100Base-FX and 10/100Base-T
N | | | | | | | | RS485 and 10/100Base-T
SOFTWARE 00 | | | | | | | No Software Options
01 | | | | | | | Ethernet Global Data (EGD); not available for Type E CPUs
03 | | | | | | | IEC 61850; not available for Type E CPUs
04 | | | | | | | Ethernet Global Data (EGD) and IEC 61850; not available for Type E CPUs
06 | | | | | | | Phasor Measurement Unit (PMU)
07 | | | | | | | Phasor Measurement Unit (PMU) and IEC61850
10 | | | | | | | Synchrocheck
11 | | | | | | | Synchrocheck and IEC 61850; not available for Type E CPUs
33 | | | | | | | Phasor Measurement Unit (PMU) and synchrocheck
34 | | | | | | | Phasor Measurement Unit (PMU), IEC 61850 protocol, and synchrocheck
MOUNT/COATING V | | | | | | Vertical (3/4 rack)
B | | | | | | Vertical (3/4 rack) with harsh environmental coating
FACEPLATE/ DISPLAY F | | | | | English display
D | | | | | French display
R | | | | | Russian display
A | | | | | Chinese display
K | | | | | Enhanced front panel with English display
M | | | | | Enhanced front panel with French display
Q | | | | | Enhanced front panel with Russian display
U | | | | | Enhanced front panel with Chinese display
L | | | | | Enhanced front panel with English display and user-programmable pushbuttons
N | | | | | Enhanced front panel with French display and user-programmable pushbuttons
T | | | | | Enhanced front panel with Russian display and user-programmable pushbuttons
V | | | | | Enhanced front panel with Chinese display and user-programmable pushbuttons
POWER SUPPLY H | | | | 125 / 250 V AC/DC power supply
L | | | | 24 to 48 V (DC only) power supply
PROCESS BUS MODULE | 81 | | Eight-port digital process bus module
DIGITAL INPUTS/OUTPUTS XX XX XX XX No Module
4A | 4 Solid-State (no monitoring) MOSFET outputs
4B | 4 Solid-State (voltage with optional current) MOSFET outputs
4C | 4 Solid-State (current with optional voltage) MOSFET outputs
4D | 16 digital inputs with Auto-Burnishing
4L | 14 Form-A (no monitoring) Latching outputs
67 | 8 Form-A (no monitoring) outputs
6A | 2 Form-A (voltage with optional current) and 2 Form-C outputs, 8 digital inputs
6B | 2 Form-A (voltage with optional current) and 4 Form-C outputs, 4 digital inputs
6C | 8 Form-C outputs
6D | 16 digital inputs
6E | 4 Form-C outputs, 8 digital inputs
6F | 8 Fast Form-C outputs
6G | 4 Form-A (voltage with optional current) outputs, 8 digital inputs
6H | 6 Form-A (voltage with optional current) outputs, 4 digital inputs
6K | 4 Form-C and 4 Fast Form-C outputs
6L | 2 Form-A (current with optional voltage) and 2 Form-C outputs, 8 digital inputs
6M | 2 Form-A (current with optional voltage) and 4 Form-C outputs, 4 digital inputs
6N | 4 Form-A (current with optional voltage) outputs, 8 digital inputs
6P | 6 Form-A (current with optional voltage) outputs, 4 digital inputs
6R | 2 Form-A (no monitoring) and 2 Form-C outputs, 8 digital inputs
6S | 2 Form-A (no monitoring) and 4 Form-C outputs, 4 digital inputs
6T | 4 Form-A (no monitoring) outputs, 8 digital inputs
6U | 6 Form-A (no monitoring) outputs, 4 digital inputs
6V | 2 Form-A outputs, 1 Form-C output, 2 Form-A (no monitoring) latching outputs, 8 digital inputs
INTER-RELAY
COMMUNICATIONS
(select a maximum of 1 per unit)
2A C37.94SM, 1300nm single-mode, ELED, 1 channel single-mode
2B C37.94SM, 1300nm single-mode, ELED, 2 channel single-mode
2E Bi-phase, single channel
2F Bi-phase, dual channel
2G IEEE C37.94, 820 nm, 128 kbps, multimode, LED, 1 Channel
2H IEEE C37.94, 820 nm, 128 kbps, multimode, LED, 2 Channels
72 1550 nm, single-mode, LASER, 1 Channel
73 1550 nm, single-mode, LASER, 2 Channel
74 Channel 1 - RS422; Channel 2 - 1550 nm, single-mode, LASER
75 Channel 1 - G.703; Channel 2 - 1550 nm, Single-mode LASER
76 IEEE C37.94, 820 nm, 64 kbps, multimode, LED, 1 Channel
77 IEEE C37.94, 820 nm, 64 kbps, multimode, LED, 2 Channels
7A 820 nm, multi-mode, LED, 1 Channel
7B 1300 nm, multi-mode, LED, 1 Channel
7C 1300 nm, single-mode, ELED, 1 Channel
7D 1300 nm, single-mode, LASER, 1 Channel
7E Channel 1 - G.703; Channel 2 - 820 nm, multi-mode
7F Channel 1 - G.703; Channel 2 - 1300 nm, multi-mode
7G Channel 1 - G.703; Channel 2 - 1300 nm, single-mode ELED
7H 820 nm, multi-mode, LED, 2 Channels
7I 1300 nm, multi-mode, LED, 2 Channels
7J 1300 nm, single-mode, ELED, 2 Channels
7K 1300 nm, single-mode, LASER, 2 Channels
7L Channel 1 - RS422; Channel 2 - 820 nm, multi-mode, LED
7M Channel 1 - RS422; Channel 2 - 1300 nm, multi-mode, LED
7N Channel 1 - RS422; Channel 2 - 1300 nm, single-mode, ELED
7P Channel 1 - RS422; Channel 2 - 1300 nm, single-mode, LASER
7Q Channel 1 - G.703; Channel 2 - 1300 nm, single-mode LASER
7R G.703, 1 Channel
7S G.703, 2 Channels
7T RS422, 1 Channel
7W RS422, 2 Channels
