Components and Functions (Theory)
5-26
Vivid E80/E90/E95
–
Service Manu
al
GC091052
Rev. 3
T
ransmitter board (G
TX)
Location (G
TX)
Figure
5-12.
G
TX TLP-192 board
location
LEDs
Figure 5-13.
LEDs on G
TX-192
T
able
5-3:
LEDs on the G
TX-192 board
LED
Color
Description
Comment
s
DS1
Red
DA
VID_RESET
DS2
Green
DCM_LOCKED
DS3
Green
VSS, VDD_DR1 & VLL
GOOD
S
tart up: Lit
Normal Operation: Lit
DS4
Green
TX_TRIGGER
Lit during scanning
