Renewal Parts
9-34
Vivid E80/E90/E95
–
Service Manu
al
GC091052
Rev. 3
Options - V
ivid E80/E90/E95
T
able
9-31:
Options
ITEM
PA
R
T
NUMBER
DESCRIPTION
QTY
CRU
FRU
1.
GC200105
DVD Drive with brackets an
d
cables
1N
Y
2.
5380960-2
USB Footswitch 3 button
1
Y
Y
369
371
