Other Top Console Parts replacement
Vivid E80/E90/E95 – Service Manual 8-55
GC091052 Rev. 3
Preparations
When preparing for the replacement, you must perform the
following steps:
1. Power down the Ultrasound system.
2. Disconnect the Mains Power Cable from the wall outlet.
3. Disconnect all probes and external I/O cabling.
4. Remove the Rotary buttons below the Touch screen and the
Volume button.
5. Remove the Operating Panel, Upper.
6. Remove the Bulkhead board.
7. Remove the Operating Panel, Lower. Place it on a clean
surface with the front down.
Remove the Bulkhead, Plate, Extended
The Bulkhead Plate is used to secure the Upper UI Frame to the
Lower UI Frame.
Follow this procedure to remove the
1. Remove the seven fixing screws.
2. Remove the Bulkhead Plate including the Cable Clamp.
Install the Bulkhead, Plate, Extended
Follow this procedure to install the
1. Position the Bulkhead Plate so it aligns with the holes for the
fixing screws.
2. Install the seven fixing screws as described below:
• The two upper screws are M6 x 20, Torque: 8.5 Nm.
• The next screw is M6 x 45, Torque: 8.5 Nm.
WARNING
DO NOT touch any boards with integrated circuits prior to
taking the necessary ESD precautions.
Always connect yourself, via an arm-wrist strap, to the advised
ESD connection point located on the rear of the Ultrasound
system (near the power connector).
Follow general guidelines for handling of electrostatic sensitive
equipment.
