Replacement Procedures
8-60 Vivid E80/E90/E95 – Service Manual
GC091052
Rev. 3
Preparations
When preparing for the replacement, you must perform the
following steps:
1. Power down the Ultrasound system.
2. Disconnect the Mains Power Cable from the wall outlet.
3. Disconnect all probes and external I/O cabling.
4. Remove the Rotary buttons below the Touch screen and the
Volume button.
5. Remove the Operating Panel, Upper.
6. Remove the Operating Panel, Lower. Place it on a clean
surface with the front down.
7. Remove the Handle Top Left and Handle Top Right.
8. Remove the Palm Rest Cover.
Remove the Buttons Frame UI Assy
Follow this procedure to remove the Buttons Frame UI Assy:
1. Disconnect the cable to the Buttons Frame UI Assy.
2. Gently pop the XYZ Buttons Frame out of the Palm Rest
section of the Lower OP Panel frame handle.
Install the Buttons Frame UI Assy
Follow this procedure to install the Buttons Frame UI Assy:
1. Insert the XYZ Buttons Frame into the Palm Rest section of
the Lower Op Panel frame handle.
2. Connect the cable to the XYZ Buttons Frame.
3. Ensure the XYZ Buttons Frame cable runs along the Lower
Op Panel cable channel so that the cable is not pinched
when the Palm Rest is replaced
DO NOT touch any boards with integrated circuits prior to
taking the necessary ESD precautions.
Always connect yourself, via an arm-wrist strap, to the advised
ESD connection point located on the rear of the Ultrasound
system (near the power connector).
Follow general guidelines for handling of electrostatic sensitive
equipment.
