3-16 Vivid E80/E90/E95 – Service Manual
GC091052
Rev. 3
7.
Exit ramp 1 A
8.
Frame 2 A
9.
Exit ramp base 2 A
10.
Box for accessories 1 A
11.
Top cover 1140 x 755 x 150 1 A
12.
Support plate, used to keep
Front Protection in place if
there are few or none
probes included.
1A
13.
Protectors for Top Cover 2 A
*) Material type: A:
B:
C:
D:
BB34bc with varnish C9068
BB27c with varnish C9068
PE foam, Stratocell
Wood ISPM15
Table 3-6: Packaging parts for Vivid E80/E90/E95 (Cont'd)
Item Description Qty. Material *) Illustration
To Next Page
