GE Voluson P6 BT18 - 8-46-5 Installation Procedure

To Next Page

To Previous Page

GE DRAFT VOLUSON™ P8/VOLUSON™P6

DIRECTION 5775469, R

EVISION 3 DRAFT (JULY 19, 2018) BASIC SERVICE MANUAL

Chapter 8 - Replacement Procedures 8-141

3.) Remove T-DPI from the EMI SHIELD BRACKET.

8-46-5 Installation Procedure

1.) Install the new parts in the reverse order of removal.

2.) Perform: FRU8-37: Replacement of the T-DPI - Functional Tests..

Figure 8-201 Removing the EMI SHIELD BRACKET

Figure 8-202 Bottom of T-DPI
