18
D
GB
F
E
09726-06.2018-DGbF
5| Compressor assembly
R Connection of pressure compensation line for expansion valve
7
/
16
"UNF
W Refrigerant injection connection M22 x 1,5
X Schrader connection for intermedie-pressure gauge
7
/
16
"UNF
Y Positionoftemperaturesensor/unpainted
Fig. 22
Intermediate
pressure line
(Shownwithout
insulation)
Y
R
X
W
Intermediate
pressure chamber
