8.5.4 Operating position of valves
For the positions of the manually controllable fittings for the operation of the package/chiller, see the P+I dia-
gram.
The layout and symbols used in the P+I diagram comply with the specifications of EN 1861, July 1998 Issue.
Caution!
The valves must be in operating position prior to the start-up of the package / chiller. Trouble-
free operation is only possible in this manner!
fig.30: Stop valve open
Stop valve open during normal operation
fig.31: Stop valve closed
Stop valve closed during normal operation
fig.32: Check valve
Check valve during normal operation
fig.33: Shuttable check valve
Shuttable check valve open during normal operation
Operating Manual | GEA Grasso M-Series
Screw Compressor Packages
Start-up
GEA Refrigeration Germany GmbH | P_261511_1 | Generated 01.04.2015 57
