GEA Grasso M-Series - Fig. 39 Overflow Valve, Safety Valve; Fig. 40 Pressure Controlled Check Valve; Fig. 41 Quick Acting Valve, Spring-Loaded; Fig. 42 Charging Valve, Drain Valve

fig.39: Overflow valve, safety valve
Overflow valve, safety valve
fig.40: Pressure controlled check valve
controlled self-sufficient
fig.41: Quick acting valve, spring-loaded
manually operated if necessary
fig.42: Charging valve, drain valve
–
½” connections
–
with cap
fig.43: Service valve
–
Connection Rp ¼”
–
For pressure gauge and pressure transmitter
