2| Product description
• Semihermeticsix-cylinderreciporatingcompressorwithoilpumplubrication.
• Thestreamofcoolantsuckedoutoftheevaporatorowsoverthemotorandcoolsitintensively.
In this way, the motor can be kept at a relatively low temperature level, particularly under high
loads.
• CylinderarrangementinpairsinW-design.
Name plate
Fig. 1
2.1 Short description
Valve plate
Cylinder
cover
Terminal box
Dimension and connection values can be found in Chapter 9
Transport eyelet
Discharge
shut-off valve
Oil pump
Suction
shut-off valve
Oil sight glass
Motor section
Drive section
