Product description
Structure
















Figure1: Geberit HS30 and HS50 hygiene flush units
1 Geberit HS30 and HS50 hygiene flush units with 1 or 2 water connections
2 Ball valve
3 Counternut
4 Volumetric flow rate sensor (for Geberit HS50 hygiene flush unit with sensor)
5 Coupling element (for Geberit HS30 and HS50 hygiene flush units without sensor)
6 Solenoid valve
6.1 Screen filter
6.2 Flow limiter
6.3 Solenoid valve unit with check valve
7 Control unit
8 Connection pipe
9 Insulation
10 4 spacers
11 4 fixing brackets
12 Protection box with protection box cover
13 Cover plate with mounting frame
