in.xe™ UL/CSA electrical specifications
Input rating : 120/240 VAC nominal (+ 5/- 10 %)
(2 lines required with neutral) 48 A Max,
Or: 120 VAC nominal only (+ 5/- 10%)
single line with neutral) 16 A Max,
60Hz nominal (+ 1. 5 / -1.0 Hz).
Output ratings:
Output Voltage Maximum Current Typical Device
Out 1 120/240 V 20 FLA/70 LRA (in-rush) Pump 1 High Speed
120/240 V 15 FLA/60 LRA (in-rush) Pump 1 Low Speed
Out 2* 240 V 15 FLA/60 LRA (in-rush) Pump 2
Out 3* 120/240 V 6 FLA/10 A (CP)/Blower
Out 4 120/240 V 6 FLA/10 A Ozone Generator
Out 5 120/240 V 10 A (always ON) Audio/Video device
L1 12 VAC 1 A Light
CO Communications port
Comm.connector (in.stik™)
C1 Tub side controller
Important:
• All low voltage acccessories use + 5Vdc and/or + 12 Vdc.
• All low voltage acccessories combined: 150 mA max, on + 12 Vdc.
• The maximum amperage for outputs 3 to 5 cannot exceed 12 Amps.
heat.wav™ ratings:
Voltage: 230 VAC, 50 Hz
Current: 8.7 A resistive (2kW at 230v)
5.7 A resistive (1.3 kW at 230v)
16.5 A resistive (3.8 kW at 230v)
Flow rate: Minimum of 18 GPM is required
Output ratings:
Output Voltage Maximum Current Typical Device
Out 1 230 V 15 FLA/60 LRA (in-rush) Pump 1 High & Low
Out 2* 230 V 15 FLA/60 LRA (in-rush) Pump 2
Out 3* 230 V 6 FLA/10 A (CP)/Blower
Out 4 230 V 6 FLA/10 A Ozone Generator
Out 5 230 V 10 A (always ON) Audio/Video device
L1 12 VAC 1 A Light
CO Communications port
Comm.connector (in.stik™)
C1 Tub side controller
specifications
in.xe.ce™ TUV electrical specifications
Input rating : 230/400 VAC nominal (+ 5/- 10 %)
(2-phase system) 20 A Max per phase
Or: 230 VAC nominal (+ 5/- 10 %)
(single-phase system) 40 A Max
50 Hz nominal (+ 1. 5 / -1.0 Hz)
heat.wav™ ratings:
Voltage: 120 or 240 VAC, 60 Hz
Current: 17A resistive (4 kW at 240V)
8.5 A resistive (1kW at 120v)
Flow rate: Minimum of 18 GPM is required
* Only available on IN.XE-5-XX-XXX
