Gecko waterlab - Installation of the Chamber in the Spa


Installation of the chamber in the spa
Secure the chamber in the spa (2 ways)
Use 2x #8 screws through the holes in the support.
or
Use 2x 8-32 screw to use the 2 fixations in the back of
the chamber support.
Install the desired size barb fittings provided on the
two valves
Ensure that the valves are closed before installing
the tube to the chamber system.
Note : There is no specific flow direction in the
chamber. The inlet and outlet can be connected to
any valve..
A- Remove the probe from its storage bottle
B- Remove the top cover of the chamber
C- Screw it on top of the storage bottle once the
probe has been removed
Important notice :
• The probe must be kept in temperature above
0°C (32°F)
• The probe must avoid long air exposure
(over 15 min)
Slide the probe in the chamber and handscrew
the nut
Ensure the chamber valves are open and fill the spa
Fill the spa or open the proper valve to let the water
circulate in the chamber.
Plug the probe cable connector to the short cable
on the CO module)
Follow further instruction on the app
Note :
After startup, the readings should stabilize
within  minutes after water circulation begins
in the chamber.
1
2
3
4
5
6
7
