4. Settings
4.1. Control Settings
Setting
Symbol
Description
Range
Typ kolektora
słonecznego (Solar
collector type)
This setting applies to all system schemes and enables
collector type selection.
Flat plate /
Tube
Różnica temp.
T1,T2 włącz. pompy
kolektorów (T1, T2
temperatures
differences for
activating collector
pump)
DT1
The main control delta
(temperature difference).
This setting specifies the condition for activating and
deactivating the collector pump. When the sum of the
∆1 setting and the tank temperature T2 exceeds the
temperature measured by the collector sensor T1, the
collector pump deactivates. If the sum is lower than
the T1 value, the collector pump is active.
Additionally, to ensure stable operation of the heating
system, a control hysteresis of 3°C is applied.
2…15ºC
Różnica temp.
włączenia dod.
Pompy, zaworu
(Temperatures
differences for
activating additional
pump, valve)
DT2
The auxiliary control delta
(temperature difference).
The setting is applied to controlling more extensive
systems.
2…15.ºC
Max. temp. T2
wyłączenia pompy
kolektorów (Max.
T2 temperature for
deactivating
collector pump)
T2
max
Setting associated with temperature sensor T2 located
inside the tank. This setting specifies the maximum
allowable temperature measured by the sensor T2
which, when exceeded, causes the collector pump to
stop.
10…85ºC
Min. temp. T3
uruchomienia
pompy kotła (Min.
T3 temperature for
activating boiler
pump)
T3
min
Setting applied in schemes 6 and 14. It defines the
minimum boiler pump K activation temperature.
10…85ºC
Min. temp. T4
włączenia pompy
cyrkulacyjnej (Min.
T4 temperature for
activating
circulation pump)
T4
mincyrk
Setting associated with the circulation pump and the
T4 sensor. It defines the minimum circulation pump
activation temperature (T4).
10…85ºC
Max. temp. T4
wyłączenia źródła
ciepła (Max. T4
temperature for
deactivating heat
source)
T4
max
Setting applied in more extensive schemes.
10…85ºC
Max. temp. wody
grzana z kotła C
(Max. temperature
of water heated in
boiler C)
T4
maxC
Setting applied only in scheme 14. Defines the
maximum value measured by the T4 sensor for boiler
pump control.
10…85ºC
