gefran 650 L - Cutout and Mounting Dimensions

80224_MHW_650 L - 1250 L_07-2018_ENG - 9
1.3.2. Cutout and mounting dimensions
48 mm
1.89 in
48 mm
1.89 in
80 mm
3.15 in
45 mm
10 mm
0.39 in
58 mm
2.28 in
70 mm
2.76 in
70 mm
2.76 in
45 mm
1.78 in
1.78 in
+0.6
- 0.0
+0.6 - 0.0
Figure 2 - 650 L Cutout and mounting Dimensions
1. GENERAL DESCRIPTION
