80224_MHW_650 L - 1250 L_07-2018_ENG - 56
4.9.1. S.o.A1 - Defining the signal direction of the analog output
Acronym Scrolling message Submenu Attributes
S.o.A1 ANALOG OUTPUT STATUS OUT.AN R W
The parameter shows and sets the state of analog retransmission output A1.
The active direct output corresponds to minimum with the minimum output value in voltage or current.
The active inverse output corresponds to minimum with the maximum output value in voltage or current.
The outputs can be forced so that they are always on or off.
Unit of measurement: -
Options: DIREC = Direct output
INVRS = Inverse output
OFF = Forced output inactive (minimum voltage or current value)
ON = Forced output active (maximum voltage or current value)
4.9.2. t.o.A1 - Defining the type of analog output
Acronym Scrolling message Submenu Attributes
t.o.A1 ANALOG OUTPUT TYPE OUT.AN R W
The parameter shows and sets the definition of analog output A1.
Unit of measurement: -
Options: 20MA = Output 0...20 mA
4-20M = Output 4...20 mA
10V = Output 0...10 V
2-10V = Output 2...10 V
C.20MA = Custom Output 0...20 mA
C.4-20 = Custom Output 4...20 mA
C.10V = Custom Output 0...10 V
C.2-10 = Custom Output 2...10 V
4.9.3. LO.A1 - Scale minimum
Acronym Scrolling message Submenu Attributes
LO.A1 LOW LIMIT ANALOG OUTPUT OUT.AN R W
The parameter shows and sets the scale minimum, which corresponds to minimum output value in voltage or current.
Unit of measurement: Scale points of quantity assigned to analog output.
Options: -1999...9999
4.9.4. HI.A1 - Scale maximum
Acronym Scrolling message Submenu Attributes
HI.A1 HIGH LIMIT ANALOG OUTPUT OUT.AN R W
The parameter shows and sets the scale maximum, which corresponds to maximum output value in voltage or current..
Unit of measurement: Scale points of quantity assigned to analog output.
Options: -1999...9999
4. CONFIGURATION
