7. OPERATOR GUIDE
PASS 1
ALRM1
ALRM2
ALRM3
ALRM4
TM.AL1
CN.AL1
Home page
Description/
Scrolling message
Unit of
measurement
Valid values Notes
Alarm 1 limit
ALARM SETPOINT
scale points LO.AL...HI.AL
Alarm 2 limit
ALARM SETPOINT
scale points
LO.AL...HI.AL
-999...999
If absolute alarm.
If deviation alarm.
Alarm 3 limit
ALARM SETPOINT
scale points
LO.AL...HI.AL
-999...999
If absolute alarm.
If deviation alarm.
Alarm 4 limit
ALARM SETPOINT
scale points
LO.AL...HI.AL
-999...999
If absolute alarm.
If deviation alarm.
ALARM1 alarm condition persistence (*)
TIME OF ALARM1 OVER THRESHOLD
mm.ss or hh.mm
(see parameter
tY.tM)
00.00…99.59
Read-only value
Reset by holding down
+
for a time
> 2 seconds (**) or digital input function
ALRM1 alarm event count (*)
COUNTER OF ALARM1
OVER THRESHOLD
- 0…9999
Read-only value
Reset by holding down
+
for a time
> 2 seconds (**) or digital input function
(*) the value is saved when the instrument is turned off
(**) Key reset can be inhibited using the Read-only option in the user menu definition from GF_eXpress
