CONTROL FUNCTIONS 650 L 1250 L
DIAGNOSTIC Short circuit or open circuit
RETENTIVE
MEMORY
Type EEPROM
Max. number of writes 1,000.000
SERIAL INTERFACE 650 L 1250 L
Type: RS485
Baudrate: 1200, 2400, 4800, 9600, 19.200, 38.400,
57.600,115.200 bit/s
Protocoll: MODBUS RTU
Isolated from main input
1) Programming is done with the GF_eXpress configuration program.
GENERAL DATA 650 L 1250 L
POWER SUPPLY
Operating voltage 100...240 VAC/VDC ±10%, 50/60 Hz
(on request 20...27 VAC/VDC ±10%)
Power dissipation 5 W max 10 W max
Protections Overvoltage 300 V / 35 V
Connection Screw terminals and crimp connector, max. wire section 1 mm
2
CONNECTIONS
Serial configuration port (for
USB connection)
Connector: microUSB
Inputs and outputs Screw terminals and crimp connector, max. wire section 2,5 mm
2
AMBIENT
CONDITIONS
Use Indoor
Altitude 2000 m max
Operating
temperature
-10 ... +55 °C (as per IEC 68-2-14)
Storage
temperature
-20 ... +70 °C (as per IEC 68-2-14)
Relative humidity 20...85% RH non-condensing (as per IEC 68-2-3)
PROTECTION
LEVEL
IP 65 on front panel (as per IEC 68-2-3)
ASSEMBLY
Positioning On panel, removable faceplate
Installation
regulations
Installation category: II; Pollution degree: 2
Isolation: double
DIMENSIONS
48 × 48 mm (1/16 DIN)
(1.89” x 1.89”),
Depth: 80 mm (3.15”)
48 × 96 mm (1/8 DIN)
(1.89” x 3.78”)
Depth: 80 mm (3.15”)
WEIGHT 0.16 kg (35 lb) 0.24 kg (53 lb)
CE STANDARDS
EMC
(electromagnetic compatibility)
Conforms to directive 2014/30/EU with reference to standard EN
61326-1
emission in industrial environment class A for models 650 LV, 1250
emission in residential environment class B for models 650 HV
Safety LVD conforms to directive 2014/35/EU with reference to standard
EN61010-1
