gefran BDI50 Series

App 3-7
Register No.
Sequence input status
2522H
0
Terminal S1 1 :“ON” 0:“OFF”
1
Terminal S2 1 :“ON” 0:“OFF”
2
Terminal S3 1 :“ON” 0:“OFF”
3
Terminal S4 1 :“ON” 0:“OFF”
4
Terminal S5 1 :“ON” 0:“OFF”
5
Terminal S6 1 :“ON” 0:“OFF”
Contact output
6
Relay R1 1 :“ON” 0:“OFF”
7
Relay R2 1 :“ON” 0:“OFF”
9~F
Reserved
(Note) Err6 error: Inverter gets communication error with external devices.
When inverter gets communication error:
• If the controller writes “1” to “2501H bit 2”, appears “EFO” on display.
• If the controller does not write “1” to “2501H bit 2”, appears “Err6” on display
Register No. Content
2523H frequency command(100/1Hz)
2524H Output frequency (100/1Hz)
2525H Output voltage command (10/1V)
2526H DC voltage command (1/1V)
2527H Output current (10/1A)
2528H reserved
2529H Output power (10/1 kW)
252AH PID feedback (100% / fmax , 10/1%)
252BH PID input (100% / fmax, 10/1%)
252CH TM2 AVI input value (1000 / 10V) *1
252DH TM2 ACI input value (1000 / 10V) *1
252EH reserved
252FH BDI50 identification: 0x0110
2530H Reserved
2531H Inverter temperature(10/°C)(temperature of heat sink or IGBT)
2532H The ratio of inverter and motor rated current (%)
