gefran BDI50 Series

3-19
3.4 Specifications
3.4.1 Product Specifications
230V Class : Single phase. F : Standards for built-in filter
Sizes BDI50
1004
1007
2015
2022
Output Rating
Rated Output Capacity
kVA
1.0
1.65
2.9
4.0
Rated Output Current
A
2.6
4.3
7.5
10.5
Maximum Applicable Motor
HP
0.5
1
2
3
kW
0.4
0.75
1.5
2.2
Output Voltage
V
Three-Phase, 0 to 240V
Output Frequency
Hz
Based on parameter setting 0.01~599
Input Rating
Rated Voltage, Frequency
Single-Phase, 200V to 240V, 50/60Hz
Allowable Voltage Fluctuation
+10% ~ -15%
Allowable Frequency Fluctuation
±5%
Input current
(1)
A
7.2
11
15.5
21
Allovable momentary
power loss time
s 1.0 1.0 2.0 2.0
Enclosure
IP20
230V Class : Three phase
Sizes BDI50
1007
2015
2022
3037
4055
4075
Output Rating
Rated Output Capacity
kVA
1.65
2.90
4.00
6.67
9.91
13.34
Rated Output Current
A
4.3
7.5
10.5
17.5
26
35
Maximum Applicable Motor
HP
1
2
3
5
7.5
10
kW
0.75
1.5
2.2
3.7
5.5
7.5
Output Voltage
V
Three-Phase, 0 to 240V
Output Frequency
Hz
Based on parameter setting 0.01~599
Input Rating
Rated Voltage, Frequency
Three-Phase, 200V to 240V, 50/60Hz
Allowable Voltage Fluctuation
+10% ~ -15%
Allowable Frequency Fluctuation
±5%
Input current
(1)
A
6.4
9.4
12.2
19.3
28.6
38.5
Allovable momentary
power loss time
s 1.0 2.0 2.0 2.0 2.0 2.0
Enclosure
IP20
(1) The input current is calculated value at full rated output current.
