gefran BDI50 Series User Manual

3-20
400V Class : Three phase. F : Standards for built-in filter
Sizes BDI50
2007
2015
2022
3037
3055
4075
4110
Output Rating
Rated Output Capacity
kVA
1.7
2.9
4.0
7.01
9.91
13.34
18.29
Rated Output Current
A
2.3
3.8
5.2
9.2
13.0
17.5
24
Maximum Applicable Motor
HP
1
2
3
5
7.5
10
15
kW
0.75
1.5
2.2
3.7
5.5
7.5
11
Output Voltage
V
Three-Phase, 0 to 480V
Output Frequency
Hz
Based on parameter setting 0.01~599
Input Rating
Rated Voltage, Frequency
Three-Phase, 380V to 480V, 50/60Hz
Allowable Voltage Fluctuation
+10% ~ -15%
Allowable Frequency
Fluctuation
±5%
Input current
(1)
A
4.2
5.6
7.3
10.1
14.3
19.3
26.4
Allovable momentary
power loss time
s 2.0
2.0 2.0 2.0 2.0 2.0 2.0
Enclosure
IP20
(1) The input current is calculated value at full rated output current.
BDI50 Powerloss
All inverters are equipped with internal fans (excluding BDI50 size 1):
Drive Model Power Loss (W) Heat Loss (kcal/hr)
230 V Class : single phase and three phase
BDI50-1004-...-2M/2T-… 27.0 23.2
BDI50-1007-...-2M/2T-… 45.0 38.7
BDI50-2015-...-2M/2T-… 64.0 55.0
BDI50-2022-...-2M/2T-… 70.0 60.2
BDI50-3037-...-2T-… 155.0 133.3
BDI50-4055-...-2T-… 148.0 127.3
BDI50-4075-...-2T-… 330.0 283.8
400 V Class: three phase
BDI50-2007-...-4-… 30.0 25.8
BDI50-2015-...-4-… 37.0 31.8
BDI50-2022-...-4-… 61.0 52.5
BDI50-3037-...-4-… 98.3 84.5
BDI50-3055-...-4-… 157.0 135.0
BDI50-4075-...-4-… 234.0 201.2
BDI50-4110-...-4-… 297.0 255.4
