5. Comparison list between parameter and register
Note:
Parameter register No.: GGnnH, “GG”means Group number, “nn” means Parameter number
for example: the address of Pr 08-03 is 0803H. the address of Pr 10-11 is 0A0BH.
Register
No.
Function
Register
No.
Function
Register No.
Function
Group00
Group01
Group02
0000H
00-00
0100H
01-00
0200H
02-00
0001H
00-01
0101H
01-01
0201H
02-01
0002H
00-02
0102H
01-02
0202H
02-02
0003H
00-03
0103H
01-03
0203H
02-03
0004H
00-04
0104H
01-04
0204H
02-04
0005H
00-05
0105H
01-05
0205H
02-05
0006H
00-06
0106H
01-06
0206H
02-06
0007H
00-07
0107H
01-07
0207H
02-07
0008H
00-08
0108H
01-08
0208H
02-08
0009H
00-09
0109H
01-09
0209H
02-09
000AH
00-10
010AH
01-10
020AH
02-10
000BH
00-11
010BH
01-11
020BH
02-11
000CH
00-12
010CH
01-12
020CH
02-12
000DH
00-13
010DH
01-13
020DH
02-13
000EH
00-14
010EH
01-14
020EH
02-14
000FH
00-15
010FH
01-15
020FH
02-15
0010H
00-16
0110H
01-16
0210H
02-16
0011H
00-17
0111H
01-17
0211H
02-17
0012H
00-18
0112H
01-18
0212H
02-18
0013H
00-19
0213H
02-19
0014H
00-20
