gefran BDI50 Series User Manual

4-11
Group 01- V/F Pattern selection & Setup
No. Description Range
Factory
Setting
Unit Note
01-00
Volts/Hz Patterns
1~7
1/4
-
01-01
V/F Max voltage
200V:170.0~264.0
400V:323.0~528.0
Based on 13-08 Vac
01-02
Max Frequency
0.2 ~ 599.00
50.00/60.00
Hz
01-03
Max Frequency Voltage Ratio
0.0 ~ 100.0
100.0
%
01-04
Mid Frequency 2
0.1 ~ 599.00
2.50/3.00
Hz
01-05
Mid Frequency Voltage Ratio 2
0.0 ~ 100.0
10.0/6.8
%
01-06
Mid Frequency 1
0.1 ~ 599.00
2.50/3.00
Hz
01-07
Mid Frequency Voltage Ratio 1
0.0 ~ 100.0
10.0/6.8
%
01-08
Min Frequency
0.1 ~ 599.00
1.30/1.50
Hz
01-09
Min Frequency Voltage Ratio
0.0 ~ 100.0
8.0/3.4
%
01-10
Volts/Hz Curve Modification
(Torque Boost)
0 ~ 10.0 0.0 % *1
01-11
V/F start Frequency
0.00~10.00
0.00
Hz
01-12
No-load oscillation suppression
gain
0.0~200.0 0 %
01-13
Motor Hunting Prevention
Coefficient
1~8192 800
01-14
Motor Hunting Prevention Gain 0~100
Sizes 1/2
100V/200V series: 7
others: 0
%
01-15
Motor Hunting Prevention Limit
0~100.0
5.0
%
01-16
Auto-Torque Compensation
Filter Coefficient
0.1~1000.0
0.1 ms
01-17
Auto-torque Compensation
Gain
0~100 0 %
01-18
Auto-torque Compensation
Frequency
1.30~5.00 2 Hz
Group 02- Motor parameters
No. Description Range
Factory
Setting
Unit Note
02-00
Motor No Load Current
----
By motor nameplate
A
*4
02-01
Motor Rated Current
(OL1)
----
By motor nameplate A
*4
02-02
V/F Slip Compensation
0.0 ~ 100.0
0.0
%
*1
02-03
Motor Rated Speed
----
By motor nameplate
rpm
*4
02-04
Motor Rated Voltage
----
By motor nameplate
Vac
*4
02-05
Motor Rated Power
0~22.0
By motor nameplate
kW
02-06
Motor Rated Frequency
0~599.0
By motor nameplate
02-07
Motor Auto Tuning
0: Disable
1: Static auto tuning
0
02-08
Stator Resistor Gain
0~600
by series
02-09
Rotor Resistor Gain
0~600
by series
02-10
Reserved
02-11
Reserved
02-12
Reserved
02-13
SLV Slip
Compensation Gain
0~200 by series %
02-14
SLV Torque
Compensation Gain
0~200 100 %
