gefran DIGISTAR II User Manual

19
80544B_MHW_DIGISTAR II - DIGISTAR II Control - GF-BOX_02-2013_ENG
Parallel Port LPT1 (13)
The parallel port is available with the standard connector DB25 female. The data lines are bi-directional, while the
control lines are simplex (input or output, according to the type of signal).
The table indicates the pinouts:
PARALLEL PORT LPT1
Pin number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
Dir
O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I
I
I
I
O
I
O
O
Signal
STB
PD0
PD1
PD2
PD3
PD4
PD5
PD6
PD7
ACK
BUSY
PE
SLCT
AFD
ERR
INIT
SLIN
GND
GND
GND
GND
GND
GND
GND
GND
Function
Output data strobe
Data
Data
Data
Data
Data
Data
Data
Data
Character accepted
Printer busy
Paper error
Printer selected
Autofeed
Printer error
Initialize printer
Select printer
Signal Ground
Signal Ground
Signal Ground
Signal Ground
Signal Ground
Signal Ground
Signal Ground
Signal Ground
