20
80544B_MHW_DIGISTAR II - DIGISTAR II Control - GF-BOX_02-2013_ENG
Floppy Disk Interface (14)
Connection to an FDD is available through a DB37 female connector according to the layout defined in the
following table.
The connector provides power supply of 5V for the FDD.
CONNECTOR
Pin number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
Signal
GND
N.C.
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
N.C.
Signal
DENSEL
N.C.
N.C.
INDEX
MTR0
DRV1
DRV0
MTR1
DIR
STEP
WDATA
WGATE
TRKO
WRPRT
RDDATA
HDSEL
DSKCHG
VCC (+5V)
Pin number
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
