gefran GFX4-IR Configuration And Programming Manual

18
80415F_MSW_GFX4-IR_05-2019_ENG
420
o.tU3
R/W
Offset correction for TV input
(phase 3)
-99.9 ...99.9
Scale points
0.0
With 3-phase load
419
o.tU2
R/W
Offset correction for TV input
(phase 2)
-99.9 ...99.9
Scale points
0.0
With 3-phase load
Setting the offset
493
1.tU3
R
Value of voltmeter input (phase 3)
With 3-phase load
492
1.tU2
R
Value of voltmeter input (phase 2)
With 3-phase load
232
485
1.tU1
R
Value of voltmeter input (phase 1)
411
o.tU1
R/W
Offset correction for TV input
(phase 1)
-99.9 ...99.9
Scale points
0.0
Read state
322
1.UF1
R
Value of voltmeter input (phase 1)
496
1.UF2
R
Value of voltmeter input (phase 2)
With 3-phase load
497
1.UF3
R
Value of voltmeter input (phase 3)
With 3-phase load
712
I.U13
R
Linked voltage V13
711
I.U32
R
Linked voltage V32
710
I.U21
R
Linked voltage V21
315
FREq
R
Voltage frequency in tenths of Hz
702
R
Voltage status 5
bit
0 frequency_warning
1 10% umbalanced_line_warning
2 20% umbalanced_line_warning
3 30% umbalanced_line_warning
4 rotation 123_error
5 triphase_missing_line_error
6 60Hz
Voltage status 5
