3380415F_MSW_GFX4-IR_05-2019_ENG
Alarm setpoints
80.0
0.0 ... 100.0%
10.0
With 3-phase load
10.0
With 3-phase load
737
xb.P
R/W
Percentage HB alarm setpoint of
current read in HB calibration
503
A.xb3
R/W
HB alarm setpoint (scale points amme-
ter input - Phase 3)
502
A.xb2
R/W
HB alarm setpoint (scale points amme-
ter input - Phase 2)
55
A.xb1
R/W
HB alarm setpoint (scale points amme-
ter input - Phase 1)
10.0
112 bit
Calibration HB
alarm setpoint for
zone
R/W
OFF = Calibration not enabled
ON = Calibration enabled
NB: In case of 3-phase load, you can set a different value for parameter A.Hb1,
A.Hb2, A.Hb3 for each zone (ex.: to control an unbalanced 3-phase load).
0.0
0.0
0.0
759
Ir.01
R/W
HB Calibration with IR lamp: current at
50% conduction
758
Ir.00
R/W
HB Calibration with IR lamp: current at
100% conduction
743
xb.Pw
R
Ou.P power in HB calibration
742
xb.tA
R
CT read in HB calibration
0.0
0.0
760
Ir.02
R/W
HB Calibration with IR lamp: current at
30% conduction
0.0
761
Ir.03
R/W
HB Calibration with IR lamp: current at
20% conduction
Enable alarm
57
Xb.f
R/W
HB alarm functions
0 Relay, logic output: alarm active at a load current value below
set point for control output ON time.
1 Relay, logic output: alarm active at a load current value above
set point for control output OFF time.
2 Alarm active if one of functions 0 and 1 is active
(OR logic between functions 0 and 1) (*)
3 Continuous heating alarm
7 Continuous cooling alarm
(*) minimum setpoint is set at 12% of ammeter full scale
Default:
SINGLE-PHASE LOAD: each A.HbX refers to its respective phase.
2-PHASE LOAD: single reference setpoint A.Hb1 and OR between phases 1, 2 and
phases 3, 4.
3-PHASE LOAD: single reference setpoint A.Hb1 and OR among phases 1, 2 and 3.
+ 8 HB reverse alarm
+ 16 relates to single setpoints and singled phases WITH 3-PHASE LOAD
Table of HB alarm functions
195
AL.n
R/W
Select number of enabled alarms
See: Table of enable alarms
3
0
56
XB.T
R/W
Delay time for activation of HB alarm
The value must exceed the cycle time of the
output to which the HB alarm is associated.
0 ... 999 sec
30
464
R/W
STATUS 11_W
0
Table settings STATUS 11_W (*)
bit
5 Feedback calibration
6 HB alarm calibration
(*) To safeguard the other bit, writing should
be done starting from the reading going to
change only the bit interested.
0.0
767
Ir.04
R/W
HB Calibration with IR lamp
(only for PA modality): current at 15%
conduction
0.0
768
Ir.05
R/W
HB Calibration with IR lamp
(only for PA modality): current at 10%
conduction
0.0
769
Ir.06
R/W
HB Calibration with IR lamp
(only for PA modality): current at 5%
conduction
