gefran GFX4-IR Configuration And Programming Manual

34
80415F_MSW_GFX4-IR_05-2019_ENG
Read state
26
bit
HB ALARM STATE OR
POWER_FAULT
OFF = Alarm off
ON = Alarm on
R
504
R
HB alarm states ALSTATE_HB (for
3-phase loads)
bit
0 HB TA2 time ON
1 HB TA2 time OFF
2 HB alarm TA2
3 HB TA3 time ON
4 HB TA3 time OFF
5 HB alarm TA3
Table of HB alarm states
512
R
States of alarm ALSTATE
bit
4 HB alarm time ON
5 HB alarm time OFF
6 HB alarm
Table of alarm states ALSTATE
76
bit
State of HB alarm
phase 1
R
77
bit
State of HB alarm
phase 2
with 3-phase loads
R
78
bit
State of HB alarm
phase 3
with 3-phase loads
R
744
xb.tr
R
HB alarm setpoint as function
of power on load
318
R
State of alarms ALSTATE IRQ
bit
0 State AL.1
1 State AL.2
2 State AL.3
3 State AL.4
4 State AL.HB (if 3-phase or phase 1/2/3)
or Power Fault
5 State AL.HB PHASE 1 (if 3-phase)
6 State AL.HB PHASE 2 (if 3-phase)
7 State AL.HB PHASE 3 (if 3-phase)
States of alarm table
