gefran GFX4-IR Configuration And Programming Manual

6780415F_MSW_GFX4-IR_05-2019_ENG
346
R Jumper
bit OFF ON
0 State jumper S1
1 State jumper S2
2 State jumper S7-1: (x) Single-phase 3-phase
3 State jumper S7-2: (x) Star Delta
4 State jumper S7-3: (x) Open delta Closed delta
5 State jumper S7-4: (x) With neutral Without neutral
6 Stato jumper S7-5: resistive load inductive load
7 State jumper S7-6: - CFG forced
8 State jumper S7-7: GFX4 Simulation 4 GFX
Table of jumper states
With / without neutral OFF ON
Open delta / excluded
Star/Delta
Single-phase/ 3-phase
S7- 1 S7- 2 S7- 3 S7- 4 x) FUNCTION MODES
OFF OFF OFF OFF 4 single-phase loads
OFF ON OFF OFF/ON 3 independent single-phase loads in open delta
ON ON OFF OFF/ON 3-phase load open delta
ON ON ON OFF/ON 3-phase load closed delta
ON OFF - ON 3-phase star load without neutral
ON OFF - OFF 3-phase star load with neutral
197
Ld.st
R/W
RN LED status function
16
0 RUN
1 MAN/AUTO controller
2 LOC / REM
3 HOLD
4 Selftuning on
5 Autotuning on
6 Repeat digital input D1
7 Serial 1 dialog
8 State of OUT 2 zone 1
9 Softstart running
10 Indication of SP1...SP2 (SP1 with pilot input inactive and LED off)
11 Repeat digital input D2
12 Input in error (LO, Hi, Err, Sbr)
13 Serial 2 dialog
+ 16 LED ashing if active (code 8 excluded)
Table of RN LED functions
619
Ld.2
R/W
ER LED status function
12
620
Ld.3
R/W
Function of LED DI1
6
621
Ld.4
R/W
Function of LED DI2
11
622
Ld.s
R/W
Function of LED O1
1
0 Disabled
1 Repetition of state OUT 1
2 Repetition of state OUT 2
3 Repetition of state OUT 3
4 Repetition of state OUT 4
5 Repetition of state OUT 5
6 Repetition of state OUT 6
7 Repetition of state OUT 7
8 Repetition of state OUT 8
9 Repetition of state OUT 9
10 Repetition of state OUT 10
+ 16 LED ashing if active
Table of OUT LED functions
623
Ld.6
R/W
Function of LED O2
2
624
Ld.7
R/W
Function of LED O3
3
625
Ld.8
R/W
Function of LED O4
4
LED status refers to the corresponding parameter, with the following special cases:
- LED RN (green) + LED ER (red) both ashing rapidly: autobaud in progress
- LED ER (red) on: error in one of main inputs (Lo, Hi, Err, Sbr)
- LED ER (red) ashing: temperature alarm (OVER_HEAT or TEMPERATURE_SENSOR_BROKEN) or SHORT-CIRCUIT_CURRENT alarm
(only in three-phase conguration)
- LED ER (red) + LED Ox (yellow) both ashing: HB alarm or POWER_FAIL in zone x
- All LEDs ashing rapidly: ROTATION123 alarm (only in three-phase conguration)
- All LEDs ashing rapidly except LED DI1: jumper conguration not provided for
- All LEDs ashing rapidly except LED DI2: 30%_UNBALANCED_LINE_WARNING alarm (only in three-phase conguration)
- All LEDs ashing rapidly except LED O1: SHORT_CIRCUIT_CURRENT alarm (only in three-phase conguration)
- All LEDs ashing rapidly except LED O2: TRIPHASE_MISSING_LINE_ERROR alarm (only in three-phase conguration)
120
R
Manufact - Trade Mark (Gefran)
5000
Name of the manufacture
121
R
Device ID (GFX4-IR)
212
Product identier

gefran GFX4-IR Specifications

General

Brand	gefran
Model	GFX4-IR
Category	Controller
Language	English
