68
80415F_MSW_GFX4-IR_05-2019_ENG
305
R/W
bit
0 -
1 Select SP1/SP2
2 Start/Stop Selftuning
3 Select ON/OFF
4 Select AUTO/MAN
5 Start/Stop Autotuning
6 Select LOC/REM
Table of instrument settings
467
R
Instrument state
bit
0 AL.1 or AL.2 or AL.3 or AL.4 or ALHB.TA1 or ALHB.TA2 or ALHB.TA3 or Power Fault
1 Input Lo
2 Input Hi
3 Input Err
4 Input Sbr
5 heat
6 cool
7 LBA
8 AL.1
9 AL.2
10 AL.3
11 AL.4
12 ALHB or Power Fault
13 ON/OFF
14 AUTO/MAN
15 LOC/REM
Table of instrument state
Current instrument state (STATUS_W)
698
R
Instrument state saved in eeprom
(STATUS_W_EEP)
469
R
Instrument state 1
bit
0 AL.1 or AL.2 or AL.3 or AL.4 or ALHB.TA1 or ALHB.TA2 or ALHB.TA3 or Power Fault
1 Input Lo
2 Input Hi
3 Input Err
4 Input Sbr
7 LBA
8 AL.1
9 AL.2
10 AL.3
11 AL.4
12 ALHB.TA1
13 ALHB.TA2 (only for three-phase load)
14 ALHB.TA3 (only for three-phase load)
15 Selftuning on
Table of instrument state 1
632
R
Instrument state 2
bit
0 AL.1
1 AL.2
2 AL.3
3 AL.4
4 AL.HB1
5 AL.HB2 (only for three-phase load)
6 AL.HB3 (only for three-phase load)
7 AL.Lo
8 AL.Hi
9 AL.Err
10 AL.Sbr
11 AL.LBA
12 AL.Power
Table of instrument state 2
633
R
Instrument state 3
bit
3 SSR_SHORT1
4 SSR_SHORT2 (only for three-phase load)
5 SSR_SHORT3 (only for three-phase load)
6 NO_VOLTAGE1
7 NO_VOLTAGE2 (only for three-phase load)
8 NO_VOLTAGE3 (only for three-phase load)
9 NO_CURRENT1
10 NO_CURRENT2 (only for three-phase load)
11 NO_CURRENT3 (only for three-phase load)
Table of instrument state 3
