HETEROGENEOUS power control
Available only for Mod. 80 kW 57A full scale
This function matches that of a thermal cutout that disconnects the load based on instantaneous input. The load is
disconnected based on a preset priority.
Zone 1 has priority: in case of overload, zone 4 is disconnected, followed by zone 3, etc.
The maximum total controllable current in four zones for the 80 kW model is 160A.
The maximum current in a single zone is 57A.
Example: you can control three 50A loads and one 10A load without limits. With four 50A loads, if there is simultaneity,
the load connected to zone 4 is disconnected.
683
I.XET
R/W
Maximum current for heterogeneous
power control
0,0 ... 64,0 for GFX4 30 kW
0,0 ... 128,0 for GFX4 60 kW
0,0 ... 160,0 for GFX4 80 kW
0,0 ... 999,9 for GFXTERMO4
0,0
Heterogeneous power table
682
hd.4
R/W
Enable heterogeneous
power control
0
ZONE 1 ZONE 2 ZONE 3 ZONA 4
0
1 X
2 X
3 X X
4 X
5 X X
6 X X
7 X X X
8 X
9 X X
10 X X
11 X X X
12 X X
13 X X X
14 X X X
15 X X X X
NOTE: Only for GFX4 with CTs.
In case of GFXTERMO4, the 4 CTs must be connected to outputs OUT1...OUT4.
Table for enabling heterogeneous power
681
I.XEU
R/W
Maximum current for heuristic power
control
0,0 ... 64,0 for GFX4 30 kW
0,0 ... 128,0 for GFX4 60 kW
0,0 ... 160,0 for GFX4 80 kW
0,0 ... 999,9 for GFXTERMO4
0,0
Heuristic power table
680
hd.3
R/W
Enable heuristic
power control
0
ZONE 1 ZONE 2 ZONE 3 ZONE 4
0
3 X X
5 X X
6 X X
7 X X X
9 X X
10 X X
11 X X X
12 X X
13 X X X
14 X X X
15 X X X X
NOTE: Only for GFX4 with CTs present and outputs OUT1...OUT4 with slow cycle time
(1...200sec) all HEAT or all COOL.
In case of GFXTERMO4, the 4 CTs must be connected to outputs OUT1...OUT4.
Table for enabling heuristic power
