PID HEAT/ COOL CONTROL
617
spu
R/W
Enable zone process variable
180
(tr
R/W
Control type
5
148 - 149
h.pb
R/W
Proportional band for heating or
hysteresis ON/OFF
7
150
h.1t
R/W
Integral heating time
8
151
h.dt
R/W
Derivative heating time
6
c.pb
R/W
Proportional band for cooling or
hysteresis ON/OFF
76
c.1t
R/W
Integral cooling time
77
c.dt
R/W
Derivative cooling time
513
(.Me
R/W
Select cooling uid
152
9
(t.1
R/W
Cycle time OUT 1 (Heat)
159
(t.2
R/W
Cycle time OUT 2 (Cool)
2
132 - 471
0v.p
R
Value control outputs
(+Heat / -Cool)
39
484
c.sp
R/W
Cooling setpoint relative to heating
setpoint
78
rst
R/W
Manual reset
(value added to PID input)
516
p.rs
R/W
Reset power
(value added directly to PID output)
79
a.rs
R/W
Antireset
(limits integral PID action)
80
ffd
R/W
Feedforward (value added to PID output
after processing)
42
146
h.p.x
R/W
Maximum limit heating power
254
h.p.L
R/W
Min. limit heating power (not available
for double action heat/cool)
43
c.p.x
R/W
Maximum limit cooling power
255
c.p.L
R/W
Min. limit cooling power (not available
for double action heat/cool)
AUTOMATIC/MANUAL CONTROL
140
diG.
R/W
Digital input function
618
diG.2
R/W
Digital input function 2
1
bit
AUTO/MAN
OFF = Automatic
ON = Manual
R/W
305
R/W
Instrument state
2
132 - 471
0v.p
R
Value control outputs
(+Heat / -Cool)
766
P.oFS
R/W
Offset of output power
765
P..pEr
R/W
Percentage of output power
