SETPOINT SETTINGS
181
tp.2
R/W
Auxiliary analog input function
138
16 - 472
_
sp
R/W
Local setpoint
18
136 - 249
SP.r
R/W
Remote setpoint (SET Gradient for
manual power correction)
25
20 - 28 - 142
Lo.L
R/W
Lowest settable limit SP, SP remote and
absolute alarms
26
21 - 29 - 143
xI.L
R/W
Highest settable limit SP, SP remote and
absolute alarms
10
bit
LOCAL / REMOTE
OFF = Enable local setpoint
ON = Enable remote setpoint
R/W
305
R/W
Instrument state
SETPOINT CONTROL
234
22
g.sp
R/W
Set Gradient
259
g.s2
R/W
Set Gradient for SP2
265
xot
R/W
Select hot runner functions
191
hd.1
R/W
Enable multiset instrument
control via serial
230
482
SP.1
R/W
Setpoint 1
231
483
SP.2
R/W
Setpoint 2
140
diG.
R/W
Digital input function
618
diG.2
R/W
Digital input function 2
75
bit
SELECT
SP1 / SP2
OFF = Select SP1
ON = Select SP2
R/W
305
R/W
Instrument state
1
137 - 481
spa
R Active setpoint
4
R
Deviation (SPA - PV)
