19
Subject to technical modications
5. Remove the 2nd sensor from the carrying case and complete steps 1 to 4.
– The sensor must be positioned parallel to the tie bar!
– The 2nd sensor pair must be placed exactly opposite (180°) and
parallel to the 1st sensor at the same position!
Correct!
Incorrect!
Not 180° opposite
Incorrect!
Not at same position
